A.3 Parameters
Table 22: Lead and Lag Drive Parameters
Parameter Number Parameter Name
Parameter Value
Set-up 1 Set-up 2
0–01 Language [22] English US [22]
0–03 Regional settings [1] North America [1] North America
0–10 Active set-up [9] Multi set-up [9] Multi set-up
0–11 Programming set-up [1] Set-up 1 [2] Set-up 2
0–12 This set–up linked to [0] Not linked [1] Set-up 1
5–01 Terminal 27 mode [1] Output [1] Output
5–02 Terminal 29 mode [1] Output [1] Output
5–10 Terminal 18 digital input [8] Start [0] No operation
5–11 Terminal 19 digital input [0] No operation [0] No operation
5–12 Terminal 27 digital input [0] No operation [0] No operation
5–13 Terminal 29 digital input Jog Jog
5–14 Terminal 32 digital input [0] No operation [0] No operation
5–15 Terminal 33 digital input [23] Set-up select bit 0 [23] Set-up select bit 0
5–19 Terminal 37 Safe Stop Safe Stop Alarm Safe Stop Alarm
5–30 Terminal 27 digital output [160] No alarm [160] No alarm
5–31 Terminal 29 digital output [160] No alarm [0] No operation
5–40 Relay 1 [1] Control ready [1] Control ready
5–40.0 Function Relay [1] Control ready [1] Control ready
5–40.1 Function Relay Running Running
State controller start and stop events
13–00 SL controller mode [1] on [1] on
13–01 Start event [37] Digital input di32 [37] Digital input di32
13–02 Stop event [26] Logic rule 0 [26] Logic rule 0
13–20.0 SL controller timer 0 024:00:00.000 024:00:00.000
13–20.1 SL controller timer 1 000:00:02.000 000:00:02.000
Logic rules
13–40.0 Logic rule boolean 1 [37] Digital input di32 [37] Digital input di32
13–40.1 Logic rule boolean 1 [43] ok key [43] ok key
13–41.0 Logic rule operator 1 [5] not and [5] not and
13–41.1 Logic rule operator 1 [1] and [1] and
13–42.0 Logic rule boolean 2 [1] true [1] true
13–42.1 Logic rule boolean 2 [46] Right key [46] Right key
13–43.1 Logic rule operator 2 [2] or [2] or
13–44.1 Logic rule boolean 3 [30] SL time–out 0 [30] SL time–out 0
States
13–51.0 SL controller event [1] true [1] true
13–51.1 SL controller event [31] SL time–out 1 [31] SL time–out 1
13–51.2 SL controller event [27] Logic rule 1 [27] Logic rule 1
13–51.3 SL controller event [1] true [1] true
13–51.4 SL controller event [31] sl time–out 1 [31] sl time–out 1
13–51.5 SL controller event [27] Logic rule 1 [27] Logic rule 1
13–52.0 SL controller action [30] Start timer 1 [30] Start timer 1
13–52.1 SL controller action [29] Start timer 0 [29] Start timer 0
