D1.10 General Information M8SL2-00-002-812
© Copyright Tait Electronics Limited August 2004. All rights reserved.
Tone Frequency … 1200Hz
Valid Station ID … alphanumeric only
Repetition Rate … off or 1 to 60 minutes
Carrier Deviation … 20% nominal system deviation
(for test tone set at 60%)
1.2.9 Voting
Programmable Tone-On-Idle Frequencies … 1950, 2100, 2175, 2325, 2500, 2600,
2800, 2900, 2970, 3000 and 3100Hz
Programmable Sliding Voting Tone
Frequencies … 2700 to 3500Hz
Voting Tone Level To Line …–40dBr to –1dBr
(Adjustable relative to Line-Out
setting)
1.2.10 Miscellaneous
Auxiliary Output Rating … open collector, 50V, 250mA (at25°C)
Momentary Monitor (CTCSS Defeat) Time … off or 1 to 20 seconds
