2 Power Supply Description
2.1 Introduction
The T800-23-0011 power supply consists of a Power Supply Unit (PSU) Module, connec-
tors, and ferrite filters. These components are shown in Figure 2.1 below.
Figure 2.1 T800-23-0011 internal view. See the Parts List in Section 6.2.2 for more detail.
PSU Module
Molex Socket
(DC Output)
IEC Plug
(Mains Input)
Ferrite Sleeve
Ferrite Bead
Chassis grounding point
(Mains Ground filter)
Internal Loom
(Mains Input filter)
(DC Output filter)
Ferrite Bead
using Earth Tag
Feed through loom
from programming
port and speaker on
SL2 front panel to
back plane PCB.
