M8SL2-00-002-812 T803 PCB Information D4.1.1
© Copyright Tait Electronics Limited August 2004. All rights reserved.
4 T803 PCB Information
Caution: This equipment contains CMOS devices which are susceptible to damage from
static charges. Refer to Section 3.1 for more information on anti-static procedures
when handling these devices.
This section provides the following information on the T803.
• parts list
• grid reference index
• PCB layouts
• circuit diagrams.
Section Title IPN Page
4.1 Introduction 4.1.3
4.2 T803 Main and Front Panel PCBs 220-01581-01 4.2.1
