Tait T800 SL2 25W User Manual

IPN 220-01581-04
M8SL2-00-002-812 T803 PCB Information D4.2.3
© Copyright Tait Electronics Limited August 2004. All rights reserved.
Ref Var IPN Description Ref Var IPN Description
T803 Parts List (IPN 220-01581-04)
How To Use This Parts List
The components listed in this parts list are grouped in alphabetical order and then in numerical order within each group. Each compo-
nent entry comprises three or four columns: the circuit reference, variant (if applicable), IPN and description. A number in the variant
column indicates that this is a variant component which is fitted only to the product type listed.
This parts list is correct at the time of publishing, but is subject to change without notification. An up to date parts list can be obtained
from your local Customer Service Organisation
C1 015-24100-08 CAP CER 0805 1N 10% X7R 50V
C128 015-24100-08 CAP CER 0805 1N 10% X7R 50V
C145 015-24100-08 CAP CER 0805 1N 10% X7R 50V
C162 016-08470-01 CAP ELEC SMD 47UF 6*4 16V
C163 016-08100-01 CAP ELEC SMD 10M 4*5.2 16V 20%
C164 015-24100-08 CAP CER 0805 1N 10% X7R 50V
C165 015-24100-08 CAP CER 0805 1N 10% X7R 50V
C166 015-24100-08 CAP CER 0805 1N 10% X7R 50V
C167 016-08470-01 CAP ELEC SMD 47UF 6*4 16V
C168 016-08100-01 CAP ELEC SMD 10M 4*5.2 16V 20%
C170 015-24100-08 CAP CER 0805 1N 10% X7R 50V
C172 015-25100-08 CAP CER 0805 10N 10% X7R 50V
C173 015-25100-08 CAP CER 0805 10N 10% X7R 50V
C174 015-25100-08 CAP CER 0805 10N 10% X7R 50V
C2 016-08100-01 CAP ELEC SMD 10M 4*5.2 16V 20%
C202 015-25100-08 CAP CER 0805 10N 10% X7R 50V
C203 016-07470-06 CAP ELEC SMD BI-P 4U7 50V 20%
C204 016-07470-06 CAP ELEC SMD BI-P 4U7 50V 20%
C205 015-25220-08 CAP CER 0805 22N 10% X7R 50V
C206 015-25220-08 CAP CER 0805 22N 10% X7R 50V
C207 015-24470-08 CAP CER 0805 4N7 10% X7R 50V
C208 015-24470-08 CAP CER 0805 4N7 10% X7R 50V
C210 015-25100-08 CAP CER 0805 10N 10% X7R 50V
C211 015-23470-08 CAP CER 0805 470P 10% X7R 50V
C212 015-05330-08 CAP CER 1206 33N 10% X7R 50V
C213 015-05330-08 CAP CER 1206 33N 10% X7R 50V
C214 015-23470-08 CAP CER 0805 470P 10% X7R 50V
C215 015-23470-08 CAP CER 0805 470P 10% X7R 50V
C216 015-23470-08 CAP CER 0805 470P 10% X7R 50V
C217 015-25100-08 CAP CER 0805 10N 10% X7R 50V
C218 015-27100-10 CAP CER 0805 1M+80-20% Y5V 16V
C219 015-25100-08 CAP CER 0805 10N 10% X7R 50V
C220 015-27100-10 CAP CER 0805 1M+80-20% Y5V 16V
C222 015-24100-08 CAP CER 0805 1N 10% X7R 50V
C224 015-27100-10 CAP CER 0805 1M+80-20% Y5V 16V
C225 015-26100-08 CAP CER 0805 100N 10% X7R 50V
C226 015-24470-08 CAP CER 0805 4N7 10% X7R 50V
C227 015-26100-08 CAP CER 0805 100N 10% X7R 50V
C232 015-26100-08 CAP CER 0805 100N 10% X7R 50V
C233 015-24100-08 CAP CER 0805 1N 10% X7R 50V
C235 015-26100-08 CAP CER 0805 100N 10% X7R 50V
C236 015-26100-08 CAP CER 0805 100N 10% X7R 50V
C238 015-26100-08 CAP CER 0805 100N 10% X7R 50V
C239 015-25100-08 CAP CER 0805 10N 10% X7R 50V
C240 015-25100-08 CAP CER 0805 10N 10% X7R 50V
C242 015-26100-08 CAP CER 0805 100N 10% X7R 50V
C3 015-24100-08 CAP CER 0805 1N 10% X7R 50V
C300 015-25100-08 CAP CER 0805 10N 10% X7R 50V
C301 015-25100-08 CAP CER 0805 10N 10% X7R 50V
C302 015-25100-08 CAP CER 0805 10N 10% X7R 50V
C303 015-25100-08 CAP CER 0805 10N 10% X7R 50V
C304 015-25100-08 CAP CER 0805 10N 10% X7R 50V
C305 015-22270-01 CAP CER 0805 27P 5% NPO 50V
C306 015-22270-01 CAP CER 0805 27P 5% NPO 50V
C307 015-25100-08 CAP CER 0805 10N 10% X7R 50V
C308 015-25100-08 CAP CER 0805 10N 10% X7R 50V
C310 015-25100-08 CAP CER 0805 10N 10% X7R 50V
C311 015-25100-08 CAP CER 0805 10N 10% X7R 50V
C312 015-24100-08 CAP CER 0805 1N 10% X7R 50V
C313 015-25100-08 CAP CER 0805 10N 10% X7R 50V
C314 015-22270-01 CAP CER 0805 27P 5% NPO 50V
C315 015-25100-08 CAP CER 0805 10N 10% X7R 50V
C316 015-25100-08 CAP CER 0805 10N 10% X7R 50V
C317 015-25100-08 CAP CER 0805 10N 10% X7R 50V
C318 015-25100-08 CAP CER 0805 10N 10% X7R 50V
C319 015-25100-08 CAP CER 0805 10N 10% X7R 50V
C320 015-25100-08 CAP CER 0805 10N 10% X7R 50V
C4 015-26100-08 CAP CER 0805 100N 10% X7R 50V
C400 015-24100-08 CAP CER 0805 1N 10% X7R 50V
C401 015-24100-08 CAP CER 0805 1N 10% X7R 50V
C402 015-24100-08 CAP CER 0805 1N 10% X7R 50V
C403 015-24100-08 CAP CER 0805 1N 10% X7R 50V
C404 015-24100-08 CAP CER 0805 1N 10% X7R 50V
C405 015-24100-08 CAP CER 0805 1N 10% X7R 50V
C406 015-24100-08 CAP CER 0805 1N 10% X7R 50V
C407 015-24100-08 CAP CER 0805 1N 10% X7R 50V
C408 015-24100-08 CAP CER 0805 1N 10% X7R 50V
C409 015-24100-08 CAP CER 0805 1N 10% X7R 50V
C410 015-24100-08 CAP CER 0805 1N 10% X7R 50V
C411 015-24100-08 CAP CER 0805 1N 10% X7R 50V
C412 015-24100-08 CAP CER 0805 1N 10% X7R 50V
C413 015-24100-08 CAP CER 0805 1N 10% X7R 50V
C414 015-24100-08 CAP CER 0805 1N 10% X7R 50V
C415 015-24100-08 CAP CER 0805 1N 10% X7R 50V
C416 015-24100-08 CAP CER 0805 1N 10% X7R 50V
C417 015-24100-08 CAP CER 0805 1N 10% X7R 50V
C418 015-24100-08 CAP CER 0805 1N 10% X7R 50V
C419 015-24100-08 CAP CER 0805 1N 10% X7R 50V
C420 015-24100-08 CAP CER 0805 1N 10% X7R 50V
C421 015-24100-08 CAP CER 0805 1N 10% X7R 50V
C422 015-24100-08 CAP CER 0805 1N 10% X7R 50V
C423 015-24100-08 CAP CER 0805 1N 10% X7R 50V
C424 015-24100-08 CAP CER 0805 1N 10% X7R 50V
C425 015-24100-08 CAP CER 0805 1N 10% X7R 50V
C426 015-24100-08 CAP CER 0805 1N 10% X7R 50V
C427 015-24100-08 CAP CER 0805 1N 10% X7R 50V
C428 015-24100-08 CAP CER 0805 1N 10% X7R 50V
C429 015-24100-08 CAP CER 0805 1N 10% X7R 50V
C430 015-24100-08 CAP CER 0805 1N 10% X7R 50V
C431 015-24100-08 CAP CER 0805 1N 10% X7R 50V
C432 015-24100-08 CAP CER 0805 1N 10% X7R 50V
C433 015-24100-08 CAP CER 0805 1N 10% X7R 50V
C434 015-24100-08 CAP CER 0805 1N 10% X7R 50V
C435 015-24100-08 CAP CER 0805 1N 10% X7R 50V
C436 015-24100-08 CAP CER 0805 1N 10% X7R 50V
C437 015-24100-08 CAP CER 0805 1N 10% X7R 50V
C438 015-24100-08 CAP CER 0805 1N 10% X7R 50V
C439 015-24100-08 CAP CER 0805 1N 10% X7R 50V
C440 015-24100-08 CAP CER 0805 1N 10% X7R 50V
C441 015-24100-08 CAP CER 0805 1N 10% X7R 50V
C442 015-24100-08 CAP CER 0805 1N 10% X7R 50V
C443 015-24100-08 CAP CER 0805 1N 10% X7R 50V
C444 015-24100-08 CAP CER 0805 1N 10% X7R 50V
C445 015-24100-08 CAP CER 0805 1N 10% X7R 50V
C446 015-24100-08 CAP CER 0805 1N 10% X7R 50V
C447 015-24100-08 CAP CER 0805 1N 10% X7R 50V
C448 015-24100-08 CAP CER 0805 1N 10% X7R 50V
C449 015-24100-08 CAP CER 0805 1N 10% X7R 50V
C450 015-24100-08 CAP CER 0805 1N 10% X7R 50V
C451 015-24100-08 CAP CER 0805 1N 10% X7R 50V
C452 015-24100-08 CAP CER 0805 1N 10% X7R 50V
C453 015-24100-08 CAP CER 0805 1N 10% X7R 50V
C454 015-24100-08 CAP CER 0805 1N 10% X7R 50V
C455 015-24100-08 CAP CER 0805 1N 10% X7R 50V
C5 016-08470-01 CAP ELEC SMD 47UF 6*4 16V
C500 015-22270-01 CAP CER 0805 27P 5% NPO 50V
C501 015-22270-01 CAP CER 0805 27P 5% NPO 50V
C502 015-22270-01 CAP CER 0805 27P 5% NPO 50V
C503 015-24100-08 CAP CER 0805 1N 10% X7R 50V
C504 015-24100-08 CAP CER 0805 1N 10% X7R 50V
C505 015-24100-08 CAP CER 0805 1N 10% X7R 50V
C506 015-24100-08 CAP CER 0805 1N 10% X7R 50V
C507 015-22270-01 CAP CER 0805 27P 5% NPO 50V
C508 015-22270-01 CAP CER 0805 27P 5% NPO 50V
C509 015-22270-01 CAP CER 0805 27P 5% NPO 50V
C510 015-24100-08 CAP CER 0805 1N 10% X7R 50V
C511 015-24100-08 CAP CER 0805 1N 10% X7R 50V
C512 015-24100-08 CAP CER 0805 1N 10% X7R 50V
C513 015-24100-08 CAP CER 0805 1N 10% X7R 50V
C514 015-22270-01 CAP CER 0805 27P 5% NPO 50V
C515 015-24100-08 CAP CER 0805 1N 10% X7R 50V
C516 015-24100-08 CAP CER 0805 1N 10% X7R 50V
C517 015-24100-08 CAP CER 0805 1N 10% X7R 50V
C518 015-24100-08 CAP CER 0805 1N 10% X7R 50V
C519 015-24100-08 CAP CER 0805 1N 10% X7R 50V
C520 015-24100-08 CAP CER 0805 1N 10% X7R 50V
C521 015-22270-01 CAP CER 0805 27P 5% NPO 50V
C522 015-24100-08 CAP CER 0805 1N 10% X7R 50V
C523 015-24100-08 CAP CER 0805 1N 10% X7R 50V
C524 015-24100-08 CAP CER 0805 1N 10% X7R 50V
C525 015-24100-08 CAP CER 0805 1N 10% X7R 50V
C526 015-24100-08 CAP CER 0805 1N 10% X7R 50V
C527 015-24100-08 CAP CER 0805 1N 10% X7R 50V
C6 016-08470-01 CAP ELEC SMD 47UF 6*4 16V
C600 015-24100-08 CAP CER 0805 1N 10% X7R 50V
C601 015-22270-01 CAP CER 0805 27P 5% NPO 50V
