Tait T800 SL2 25W User Manual

IPN 220-01581-04
M8SL2-00-002-812 T803 PCB Information D4.2.5
© Copyright Tait Electronics Limited August 2004. All rights reserved.
Ref Var IPN Description Ref Var IPN Description
R322 036-14180-00 RES M/F SMD 0805 1K8 5%
R323 036-14180-00 RES M/F SMD 0805 1K8 5%
R324 036-14180-00 RES M/F SMD 0805 1K8 5%
R325 036-14180-00 RES M/F SMD 0805 1K8 5%
R326 036-14180-00 RES M/F SMD 0805 1K8 5%
R327 036-14180-00 RES M/F SMD 0805 1K8 5%
R328 036-14180-00 RES M/F SMD 0805 1K8 5%
R330 036-14180-00 RES M/F SMD 0805 1K8 5%
R331 036-14180-00 RES M/F SMD 0805 1K8 5%
R332 036-14180-00 RES M/F SMD 0805 1K8 5%
R333 036-14180-00 RES M/F SMD 0805 1K8 5%
R334 036-14180-00 RES M/F SMD 0805 1K8 5%
R335 036-14180-00 RES M/F SMD 0805 1K8 5%
R336 036-15100-10 RES M/F SMD 0805 10K 1%
R341 036-15100-10 RES M/F SMD 0805 10K 1%
R342 036-15100-10 RES M/F SMD 0805 10K 1%
R343 036-15100-10 RES M/F SMD 0805 10K 1%
R344 036-15100-10 RES M/F SMD 0805 10K 1%
R345 036-15100-10 RES M/F SMD 0805 10K 1%
R346 036-15100-10 RES M/F SMD 0805 10K 1%
R347 036-15100-10 RES M/F SMD 0805 10K 1%
R348 036-15100-10 RES M/F SMD 0805 10K 1%
R351 036-15100-10 RES M/F SMD 0805 10K 1%
R352 036-14150-10 RES M/F SMD 0805 1K5 1%
R353 036-15100-10 RES M/F SMD 0805 10K 1%
R4 036-13330-00 RES M/F SMD 0805 330E 5%
R5 036-13220-10 RES M/F SMD 0805 220E 1%
R7 036-13330-00 RES M/F SMD 0805 330E 5%
R8 036-13220-10 RES M/F SMD 0805 220E 1%
R9 036-13330-00 RES M/F SMD 0805 330E 5%
RV1 042-05100-10 RES PRE 10K CER 9.5MM SQ FLAT
S1 230-00010-38 SW EXTENDER CAP 19MM
S2 230-00010-38 SW EXTENDER CAP 19MM
SK1 240-10000-07 CONN SMD 16W 2R SKT M/MATCH
SK100 240-04021-80 SKT 8W RJ45 HOR MTG
SK101 240-10000-07 CONN SMD 16W 2R SKT M/MATCH
SK2 240-04021-60 SKT 6W MODR PH VRT T-ENT
T200 054-00010-16 XFMR LINE 600 OHM 1:1 P1200
T201 054-00010-16 XFMR LINE 600 OHM 1:1 P1200
XL300 274-00010-59 XTAL 18.432MHZ HC49/U
