IPN 220-01145-07
M8SL2-00-002-812 T850 VCO PCB Information E2.3
© Copyright Tait Electronics Limited August 2004. All rights reserved.
Ref Var IPN Description Ref Var IPN Description
T850 VCO Parts List (IPN 220-01145-07)
How To Use This Parts List
The components listed in this parts list are grouped in alphabetical order and then in numerical order within each group. Each compo-
nent entry comprises three or four columns: the circuit reference, variant (if applicable), IPN and description. A number in the variant
column indicates that this is a variant component which is fitted only to the product type listed.
This parts list is correct at the time of publishing, but is subject to change without notification. An up to date parts list can be obtained
from your local Customer Service Organisation
#C1 A 015-21120-02 Cap Cer 0805 1p2 1% NPO 50v
#C1 B 015-21120-02 Cap Cer 0805 1p2 1% NPO 50v
#C1 C 015-21150-01 Cap Cer 0805 1p5+-0.25 NPO 50v
#C1 D 015-21150-05 Cap Cer 0805 1p5 +0.1pf 200v
C2 014-08100-00 Cap Tant SMD 10u 16v 20% 267c
C3 015-24100-08 Cap Cer 0805 1n 10% X7r 50v
#C4 A 015-21100-02 Cap Cer 0805 1po 1% NPO 50v
#C4 B 015-21100-02 Cap Cer 0805 1po 1% NPO 50v
#C4 C 015-21100-02 Cap Cer 0805 1po 1% NPO 50v
#C4 D 015-21100-02 Cap Cer 0805 1po 1% NPO 50v
C5 015-06100-08 Cap Cer 1206 100n 10% X7r 50v
#C6 A 028-02111-00 Cap Trim 16pf Piston Prec
#C6 B 028-02111-00 Cap Trim 16pf Piston Prec
#C6 C 028-02111-00 Cap Trim 16pf Piston Prec
#C6 D 028-02111-00 Cap Trim 16pf Piston Prec
#C7 A 015-21330-02 Cap 0805 3p3 +/-0.1p NPO 50v
#C7 B 015-21470-02 Cap 0805 4p7 1% NPO 50v
#C7 C 015-21680-02 Cap 0805 6p8 +/-0.1p NPO 50v
#C7 D 015-21820-02 Cap 0805 8p2 0.1 NPO 50v
#C8 A 015-22220-01 Cap Cer 0805 22p 5% NPO 50v
#C8 B 015-22220-01 Cap Cer 0805 22p 5% NPO 50v
#C8 C 015-22270-01 Cap Cer 0805 27p 5% NPO 50v
#C8 D 015-22330-01 Cap Cer 0805 33p 5% NPO 50v
C9 015-23120-01 Cap Cer 0805 120p 5% NPO 50v
#C10 A 015-21180-02 Cap 0805 1p8 1% NPO 50v
#C10 B 015-21180-02 Cap 0805 1p8 1% NPO 50v
#C10 C 015-21180-02 Cap 0805 1p8 1% NPO 50v
#C10 D 015-21180-02 Cap 0805 1p8 1% NPO 50v
C11 015-21330-02 Cap 0805 3p3 +/-0.1p NPO 50v
C12 015-24100-08 Cap Cer 0805 1n 10% X7r 50v
C13 015-24100-08 Cap Cer 0805 1n 10% X7r 50v
C14 015-23120-01 Cap Cer 0805 120p 5% NPO 50v
C16 015-23120-01 Cap Cer 0805 120p 5% NPO 50v
C17 015-23120-01 Cap Cer 0805 120p 5% NPO 50v
C18 015-22270-01 Cap Cer 0805 27p 5% NPO 50v
C19 015-05470-08 Cap Cer 1206 47n 10% X7r 50v
C21 015-23120-01 Cap Cer 0805 120p 5% NPO 50v
C22 A 015-22100-02 Cap 0805 10p +/-0.1p NPO 50v
C22 B 015-22150-01 Cap Cer 0805 15p 5% NPO 50v
C22 C 015-22150-01 Cap Cer 0805 15p 5% NPO 50v
C22 D 015-23120-01 Cap Cer 0805 120p 5% NPO 50v
C23 015-21820-02 Cap 0805 8p2 0.1 NPO 50v
C24 015-05470-08 Cap Cer 1206 47n 10% X7r 50v
D1 A 001-10015-30 Diode SMD Vcap BB153 SOD323
D1 B 001-10043-90 Diode SMD BB439 Vcap SOD323
D1 C 001-10043-90 Diode SMD BB439 Vcap SOD323
D1 D 001-10043-90 Diode SMD BB439 Vcap SOD323
D2 A 001-10015-30 Diode SMD Vcap BB153 SOD323
D2 B 001-10043-90 Diode SMD BB439 Vcap SOD323
D2 C 001-10043-90 Diode SMD BB439 Vcap SOD323
D2 D 001-10043-90 Diode SMD BB439 Vcap SOD323
L1 056-10330-02 Ind SMD 1210 330nh 10% Simid02
L2 056-10330-02 Ind SMD 1210 330nh 10% Simid02
L3 056-10330-02 Ind SMD 1210 330nh 10% Simid02
L4 056-10330-02 Ind SMD 1210 330nh 10% Simid02
L5 057-00047-10 Ind Fxd 47nh +-5% 1206
#L6 A 056-10015-03 Ind SMD 0805cs 15nh 20%
#L6 B 056-10015-03 Ind SMD 0805cs 15nh 20%
#L6 C 056-10015-03 Ind SMD 0805cs 15nh 20%
#L6 D 056-10015-03 Ind SMD 0805cs 15nh 20%
Q1 000-10009-30 Xstr SMD BFR93A NPN SOT23
Q2 000-10009-30 Xstr SMD BFR93A NPN SOT23
Q3 000-10009-30 Xstr SMD BFR93A NPN SOT23
Q4 000-10008-57 Xstr SMD BC857 PNP SOT23 SS
Q5 000-10050-00 Xstr SMD BLT50 UHF SOT22
R1 036-14390-10 Res M/F SMD 0805 3k9 1%
R2 036-14100-10 Res M/F SMD 0805 1k 1%
R3 036-13100-10 Res M/F SMD 0805 100e 1%
R4 036-12220-00 Res M/F SMD 0805 22e 5%
R5 036-12270-00 Res M/F SMD 0805 27e 5%
#R6 A 036-13100-10 Res M/F SMD 0805 100e 1%
#R6 B 036-13100-10 Res M/F SMD 0805 100e 1%
#R6 C 036-13100-10 Res M/F SMD 0805 100e 1%
#R6 D 036-13100-10 Res M/F SMD 0805 100e 1%
R7 036-14100-10 Res M/F SMD 0805 1k 1%
R8 036-12220-00 Res M/F SMD 0805 22e 5%
R9 036-14270-10 Res M/F SMD 0805 2k7 1%
R10 036-14120-00 Res M/F SMD 0805 1k2 5%
R11 036-13150-10 Res M/F SMD 0805 150e 1%
R12 036-12100-10 Res M/F SMD 0805 10e 1%
R13 A 036-12270-00 Res M/F SMD 0805 27e 5%
R13 B 036-12390-00 Res M/F SMD 0805 39e 5%
R13 C 036-12390-00 Res M/F SMD 0805 39e 5%
R13 D 036-12560-00 Res M/F SMD 0805 56e 5%
R14 036-13330-00 Res M/F SMD 0805 330e 5%
R15 036-12100-10 Res M/F SMD 0805 10e 1%
R17 A 036-14680-10 Res M/F SMD 0805 6k8 1%
R17 B 036-14680-10 Res M/F SMD 0805 6k8 1%
R17 C 036-14680-10 Res M/F SMD 0805 6k8 1%
R17 D 036-14820-10 Res M/F SMD 0805 8k2 1%
R18 036-14180-00 Res M/F SMD 0805 1k8 5%
R19 036-14100-10 Res M/F SMD 0805 1k 1%
R20 036-12180-00 Res M/F SMD 0805 18e 5%
R21 036-13330-00 Res M/F SMD 0805 330e 5%
R22 036-12100-10 Res M/F SMD 0805 10e 1%
#TL1 A 051-00005-43 Reso Tait #543 480-520
#TL1 B 051-00005-42 Reso Tait #542 435-480
#TL1 C 051-00005-41 Reso Tait #541 395-440
#TL1 D 051-00005-40 Reso Tait #540 355-395
240-00026-32 Plg 32w 1row Pcb Mtg
220-01145-07 PCB T855/856/857/870 VCO
345-00040-10 Scrw M3*6mm P/P S/T Bz
350-00016-42 Spcr 5mm Hi 8*M3 Stud 2.5*M3ho
353-00010-13 Wshr M3 S/Proof Int Bz
Variant
Code
Description
T855
(MHz)
T854
(MHz)
A Tx High — 480 to 500
B Tx Mid/Rx High 480 to 520 440 to 480
C Tx Low/Rx Mid 440 to 480 400 to 440
D Rx Low 400 to 440 —
