M8SL2-00-002-812 5
© Copyright Tait Electronics Limited August 2004. All rights reserved.
1 T800 Product Codes
The T800 product code provides information about the model, type and options fitted,
according to the conventions described below
You can identify the unit’s type by checking the product code printed on a label on the
rear of the chassis (Figure 1.1 in Part A shows typical labels). You can further verify the
type by checking the placement of an SMD resistor in the table that is screen printed
onto the PCB..
