Tait T800 SL2 25W User Manual

M8SL2-00-002-812 T855 Functional Testing B4.7
© Copyright Tait Electronics Limited August 2004. All rights reserved.
4.9 Carrier Level Mute (RSSI Fitted and Carrier Mute
Linked In)
Apply an on-channel signal from the RF generator at a level of –120dBm with
±3kHz deviation (±2.4kHz) [±1.5kHz] at 1kHz.
Increase the RF level in 2dB steps and check that the mute opens at an RF level
which corresponds with the preset level on RV235 (carrier mute), i.e. between
–115dBm and –70dBm.
