5.7.3 Synthesiser
Refer to the synthesiser circuit diagram (sheet 7) in Section 6 and the VCO circuit dia-
gram in Part E.
N
Check biasing
resistors, Q4 & Q5.
Check 9V reg.
N
Y
N
8.3V present
at VCO?
DC V present
at Q4 & Q5?
9V present at
VCO Q4/Q5?
Check Q4 C
multiplier
(synth).
No VCO RF output.
Y
DC V present at
VCO, Q1, Q2 & Q3?
Check biasing
resistors, Q1,
Q2 & Q3.
Y
N
Capacitors OK?
Check for cracks,
shorts, etc.
N
Y
Replace VCO.
Replace
if faulty.
Y
Y
N
N
N
Y
Y
Check biasing
resistors & Q1.
DC V present
on Q795 emitter?
Check 9V supply.
9V present on
Q795 divider buffer?
20V inverter
supply faulty.
20V present
on IC750 pin 8?
Check 5V reg. &
supply resistor
to each IC.
VCO out of lock.
Y
Y
Y
Continued on the next page
Y
VCO freq. correct?
Synthesiser OK.
VCO trimmer
freq. range OK?
Check VCO tuning
caps & trimmer.
VCO OK.
N
N
NN
N
Y
Y
Recheck
programming
via PGM800Win.
+5V present
at IC700, IC710
& IC740?
Does VCO trimmer
adjust for stable
control line between
3 & 16V?
Does VCO trimmer
adjust for required
frequency range
between 3 & 16V?
Is 8MHz VCO range
achieved between
3 & 16V?
N
Check #C1, L1, L2,
D1 & D2 in VCO.
AB
