IPN 220-01138-03
M8SL2-00-002-812 T800-04-0000 RSSI PCB Information B6.2.3
© Copyright Tait Electronics Limited August 2004. All rights reserved.
Ref Var IPN Description Ref Var IPN Description
T800-04-0000 Parts List (IPN 220-01138-03)
How To Use This Parts List
The components listed in this parts list are grouped in alphabetical order and then in numerical order within each group. Each compo-
nent entry comprises three or four columns: the circuit reference, variant (if applicable), IPN and description. A number in the variant
column indicates that this is a variant component which is fitted only to the product type listed.
This parts list is correct at the time of publishing, but is subject to change without notification. An up to date parts list can be obtained
from your local Customer Service Organisation
C1 015-24100-08 Cap Cer 0805 1n 10% X7r 50v
C2 015-24100-08 Cap Cer 0805 1n 10% X7r 50v
C3 015-23330-08 Cap Cer 0805 330p 10% X7r 50v
C4 015-25100-08 Cap Cer 0805 10n 10% X7r 50v
C5 015-24100-08 Cap Cer 0805 1n 10% X7r 50v
C6 015-25100-08 Cap Cer 0805 10n 10% X7r 50v
C7 015-24470-08 Cap Cer 0805 4n7 10% X7r 50v
C8 015-25100-08 Cap Cer 0805 10n 10% X7r 50v
C9 015-24100-08 Cap Cer 0805 1n 10% X7r 50v
D1 001-10000-99 Diode SMD BAV99 D-Sw SOT23
IC1 002-10003-24 IC SMD 324 4x 0-Amp S014
Q1 002-10033-46 IC SMD MC3346D Xst Aray S014
R3 036-14100-10 Res M/F SMD 0805 1k 1%
R4 036-14220-00 Res M/F SMD 0805 2k2 5%
R5 036-15560-10 Res M/F SMD 0805 56k 1%
R6 036-15390-10 Res M/F SMD 0805 39k 1%
R7 036-15100-10 Res M/F SMD 0805 10k 1%
R8 036-13680-10 Res M/F SMD 0805 680e 1%
R9 036-14820-10 Res M/F SMD 0805 8k2 1%
R10 036-16220-00 Res M/F SMD 0805 220k 5%
R11 036-13470-00 Res M/F SMD 0805 470e 5%
R12 036-16330-00 Res M/F SMD 0805 330k 5%
R13 036-16100-10 Res M/F SMD 0805 100k 1%
R14 036-16180-00 Res M/F SMD 0805 180k 5%
R15 036-15220-00 Res M/F SMD 0805 22k 5%
R16 036-17100-10 Res M/F SMD 0805 1M 1%
R17 036-15330-10 Res M/F SMD 0805 33k 1%
R18 036-14100-10 Res M/F SMD 0805 1k 1%
R19 036-15100-10 Res M/F SMD 0805 10k 1%
R20 036-15100-10 Res M/F SMD 0805 10k 1%
R21 036-16330-00 Res M/F SMD 0805 330k 5%
R22 036-14470-10 Res M/F SMD 0805 4k7 1%
R23 036-15100-10 Res M/F SMD 0805 10k 1%
R24 036-16150-00 Res M/F SMD 0805 150k 5%
R25 036-16180-00 Res M/F SMD 0805 180k 5%
R26 036-15820-00 Res M/F SMD 0805 82k 5%
R29 036-14470-10 Res M/F SMD 0805 4k7 1%
R30 036-15100-10 Res M/F SMD 0805 10k 1%
R31 036-15220-00 Res M/F SMD 0805 22k 5%
R32 036-14470-10 Res M/F SMD 0805 4k7 1%
369-00020-36 Tape Vinyl Foam 2Side 25.4*3mm
220-01138-03 PCB T700 RSSI Brd
356-00010-52 Pin Edge Mtg 0.8mm PCB Wako
