T-K3 Service Manual
Ver. 1.05
68
CONFI DENTIAL
14. Parts list
Item # Pa rt # Description Common parts fo r other units
1 EKK1D CASE ASSEMBLY
2 E KK1J FRO NT CO VER
3 EKJ62
IR BLOCKAGE PL ATE TKJr
4 EKJ09 BRACKET TKJr
5 EKJ64 JUNCTION BOX TKJr
50 EW000 SCREW M4X12 TKJr, OS, SP, TH1
51 EW001 SCREW W/W ASHE R M4X10 TK2, TKD20, TK1S, OS, SP, TM1,
M199, TH1
52 EW002 COATING SCREW M4X10 TK2, TKD2 0, TK1S, OS, SP, TM1,
M199, TH1
53 EW003 SCREW M4X10 TK2, TKD2 0, TKJr, TK1S, OS, SP, TM1, TM199, TH1
54 EC00X NYLONE CLAMP TH1
101 EKK1N BURNER ASSEMBL
SP
102 EKK1Y COMBUSTION CHAMBER SP
103 EKK1F MANIFOLD
104 EK K25 FAN MOTOR SP
105 EKK1W GAS VAL VE AS SEMB L
OS, SP
106 EKK0E FLAME ROD
107 EKK0F IGNITER ROD
108 EKK1E GAS INLET OS, SP
109 EK K34 BURNER PLATE OS, SP
110 EKK1P DAMPER SP
111 EK270 FAN DAMPER
112 EKN61 ROD CAP TKJr, TK1 S, OS, SP, TH1
113 EKK2Z GAS INLET RING OS, SP
114 EKK2V BURNER WINDOW OS, SP
115 EKK2W ROD HOLDER GASKET OS, SP
116 EKK32 ROD HOLDER OS, SP
117 EKK0G BURNER HOLDER GASKET OS, SP
118 EKK2D PRESSURE PORT SP
119 EKK2N URETHAN TUBE SP
120 EKK2Y MANIFOLD G ASKET OS, SP
121 EK K20 GFI PLA TE
122 EKK1B IGNITER PLATE
123 EM167 WIRE CLAMP 60 TK2
TKD20
TKJr
TK 1S
OS
SP
TM1
TM199
TH1
150 EW003 SCREW M4X10 TK2, TKD2 0, TKJr , TK 1S, OS, SP , TM1, TM199, T-H1
151 EW002 COATING SCREW M4X10 TK2, TKD20, TKJr , TK 1S, OS, SP , TM1, TM199, T-H1
152 EK K37 SCREW M4X12 OS, SP
153 EW004 HEX HE AD SCREW M4X12 TK2
TKD20
SP
TH1
154 EW005 HEX HE AD SCREW M4X8 TK2, TKD2 0, OS, SP , TH1
155 EW006 SCREW M4X10 TK2, TKD2 0, OS, SP , TH1
156 EW00B SCREW M3X8 SP
157 EW008 SCREW M3X10 TK2, TKJr , TK 1S, OS, S P, TM1, TM199
401 EKK1X HEAT E XCHANGER A SSEMBL
402 EKK0T
FLOW ADJUSTMENT VALVE
W/FLOW SENSOR
403 EKK0U BYPASS VALVE
404 EKK1U WATER INLET OS, SP
405 EKK1V WATER OUTLE T OS, SP
