Takeuchi TB108 User Manual

137
SPECIFICATIONS
MASS
Machine mass kg (lb.)
(not including operator)
With rubber crawlers 855 (1880) 810 (1790)
PERFORMANCE
Bucket capacity m
3
(cu.ft.)
(standard bucket)
Heaped 0.018 (0.64)
Struck 0.013 (0.46)
Slew speed min
–1
(rpm) 9.3 (9.3)
Ground pressure
kPa (psi)
With rubber crawlers 25.1 (3.64) 23.8 (3.46)
ENGINE
Manufacturer and model Yanmar 2TNV70-PTB diesel engine
Rated output kW / min
–1
(hp / rpm) 7.1 / 2400 (9.6 / 2400)
Displacement mI (cu.in.) 569 (34.7)
Starter V - kW 12 - 1.0
Alternator V - kW 12 - 0.18
Battery V - Ah 12 - 34
Travel speed km/h (mph)
1st 2.0 (1.24)
2nd 3.9 (2.42)
Gradeability (degrees) 25
TYPE With CANOPY CANOPY Less
Noise level dB(A)
Sound-power level L
WA
91
Sound-pressure level L
pA
80
Rubber crawler
Main Specifications

Takeuchi TB108 Specifications

General

Max Reach	3, 480 mm
Width	980 mm
Max Reach at Ground Level	3, 480 mm
Transport Width	980 mm
Engine Power	8.1 kW (10.9 hp)
Engine Gross Power	8.1 kW (10.9 hp)
