Takeuchi TB108 User Manual

160
OPTIONS
Seat Belt
CAUTION
Always fasten the seat belt securely
before starting the engine.
Fastening the seat belt
1. Adjust the seat to the optimum position
for operating, raise your torso, and sit back
firmly into the seat.
2. Pull on adjuster (A) in the manner shown
in the diagram to adjust the seat belt to
the desired length.
3. Make sure that the belt is not twisted and
then insert the tongue plate (B) into the
buckle (C) of the seat belt until you hear a
clicking sound as it locks in place.
4. Pull the belt until you can feel the pressure
on your pelvis with the belt firmly in place.
Releasing the seat belt
1. To remove the seat belt, simply press the
button (D) located on the buckle. Once the
belt has been removed, reinsert the
tongue plate into the buckle so that seat
belt remains in full view.
C4C010
A
90°
C4C011
B
C
C4C012
D

Takeuchi TB108 Specifications

General

Max Reach	3, 480 mm
Width	980 mm
Max Reach at Ground Level	3, 480 mm
Transport Width	980 mm
Engine Power	8.1 kW (10.9 hp)
Engine Gross Power	8.1 kW (10.9 hp)
