Takeuchi TB108 User Manual

158
OPTIONS
Travel Alarm
An alarm is sounded when the machine
travels and stops when traveling is stopped.
If the alarm does not sound when the
machine travels, the fuse may be blown.
Inspect the fuse.
WARNING
If the fuse which has just been replaced
should blow again, there is a problem in
the electrical system. This could cause
fires. Contact a Takeuchi sales or service
outlet.
1. Park the machine in a safe place.
2. Set the starter switch to OFF.
3. Open the fuse holder and inspect for blown
fuses.
4. If a fuse is blown, replace it with a spare
fuse of the same capacity.
10A Horn
10A Water temperature gauge
10A Boom light, Travel alarm
30A Stop solenoid
Fuse Layout and Circuits Protected
Capacity Protected circuit
1
B5J004
E4J007
NormalBlown

Takeuchi TB108 Specifications

General

Max Reach	3, 480 mm
Width	980 mm
Max Reach at Ground Level	3, 480 mm
Transport Width	980 mm
Engine Power	8.1 kW (10.9 hp)
Engine Gross Power	8.1 kW (10.9 hp)
