40
CONTROLS
Seat and Seat Belt
Seat
WARNING
Adjust, secure and latch the operator’s
seat.
Fore-and-aft adjustment
1. Pull on lever and slide the seat backward
or forward to bring it to the optimum
position for operating the machine.
2. Release the lever at the desired position
and the seat will remain fixed there.
Seat Belt
CAUTION
Always fasten the seat belt securely
before starting the engine.
Fastening the seat belt
1. Adjust the seat to the optimum position
for operating, raise your torso, and sit back
firmly into the seat.
2. Pull the seat belt to the desired length.
3. Make sure that the belt is not twisted and
then insert the tongue plate (A) into the
buckle (B) of the seat belt until you hear a
clicking sound as it locks in place.
Releasing the seat belt
1. To remove the seat belt, simply press the
button (C) located on the buckle.
The seat belt is automatically stowed
away.
B5B005
E4B023
B
A
E4B024
C
