CONTROLS
Accessories
The operating pattern of the left and right operating levers can be changed.
WARNING
Be careful to check which pattern of lever control arrangement you are operating with
before beginning operations.
Switching the Lever Pattern
(A) : ISO pattern
(G): JCB pattern
1. Remove the lower mount section of the
boots and turn them upwards.
2. Loosen the bolts and remove the cover.
3. Switch rod (2) to plate (3).
4. Switch rod (4) to plate (5).
5. Set the boots and cover back as they
were.
6. Check the lever pattern.
ISO
A
JCB
G
C4L004

Takeuchi TB108 Specifications

General

Max Reach	3, 480 mm
Width	980 mm
Max Reach at Ground Level	3, 480 mm
Transport Width	980 mm
Engine Power	8.1 kW (10.9 hp)
Engine Gross Power	8.1 kW (10.9 hp)
