Takeuchi TB108 User Manual

71
OPERATION
Operating Procedures
Traveling Posture
Traveling up slopes
When traveling up slopes at an angle of 15°
or greater, travel in the posture shown in the
diagram above.
Traveling down slopes
When traveling down slopes at an angle of
15° or greater, lower the engine speed and
travel in the posture shown in the diagram
above.
Braking when traveling down slopes
When traveling down slopes, the brakes are
applied automatically when the travel levers
are returned to the neutral position.
If the crawlers slip
If the crawlers slip while traveling up a slope,
use the pulling force of the arm to climb the
slope.
If the engine stops
If the engine stops when traveling down a
slope, set the travel levers to the neutral
position, stop the machine, then start the
engine.
E4D045E
Braking
E4D046
Climbing
Descending
E4D047E

Takeuchi TB108 Specifications

General

Max Reach	3, 480 mm
Width	980 mm
Max Reach at Ground Level	3, 480 mm
Transport Width	980 mm
Engine Power	8.1 kW (10.9 hp)
Engine Gross Power	8.1 kW (10.9 hp)
