List of additional
control codes
Sequences Function
<ESC>[?10~ Barcode Off
<ESC>[?11~ Barcode On
<ESC> PSC 0 <ESC> \ Unsecured mode
<ESC> PSC 1 <ESC> \ Secured mode
<ESC> PLS 01 <ESC> \ LCP-CG: US ASCII
<ESC> PLS 02 <ESC> \ LCP-CG: German
<ESC>[<n><SP>s Sends a character as ASCII character; n > 0-255 decimal
Codes Function
old: new:
<DC4> <ESC>[20<SP>s Barcode bracket
<DLE> <ESC>[16<SP>s Start code LCP Header
<EM> <ESC>[25<SP>s Termination code Header
<SI> <ESC>[15<SP>s LCP bracket
<SUB> <ESC>[26<SP>s Start code barcode Header
Old codes as well as new codes are applicable.
Header Function
<DLE> [!] nn EM LCP Header
[ ] = Optional
nn = Factor
<SUB> [F] a [nn][;xyz] EM Barcode Header
[ ] = Optional
a = Barcode type
Additional information is provided in the Barcode Programmer’s Applica-
tion Manual available from your dealer (see Appendix D).
List of additional control codes
2 - 20
