Tally T2030 - Interface Cable RS232 C

Interface cable RS232C
PC/AT (9 pin) Printer (25 pin)
RxD 2 2 TxD
TxD 3 3 RxD
CTS 8 11 RDY
SG 5 7 SG
DSR 6
DTR 4
PC (25 pin) Printer (25 pin)
FG 1 1 FG
TxD 2 3 RxD
RxD 3 2 TxD
CTS 5 11 RDY
SG 7 7 SG
DSR 6
DTS 20
With this interface cable hardware as well as software protocols can be
carried out.
4
B
Serial interface RS232C/V.24
B - 5
