7
Models PH71/PH84 Operator Parts Identification
PH84 Parts Id en t ificatio n
ITEM DESCRIPTION PART NO.
1 COVER-HOPPER 053809
2 AGITATOR A. *HT*20 QT. X44797
3 PANEL -UPPER SIDE LEFT 028822
4 PAN-DRIP 17-1/4”LONG 027504
5 STUD-NOSE CONE 022822
6 PANEL A.-SIDE LOWER LEFT X46447 -SER
7 PANEL -SERVICE 046172
8 ADAPTOR A.-CASTER X18915
9 PANEL -REAR 051076
10 PANEL-UPPER SIDE RIGHT 028823
11 PANEL A.-SIDE LOWER RIGHT X46448 -SER
12 SHIELD -SPLASH-WIRE 046170
ITEM DESCRIPTION PART NO.
13 TRAY-DRIP 22-13/16 X 5-1/8 046171
14 PANEL A.-FRONT X46167
15 CASTER-SWV 5/8 STEM 4IN 018794
16 LOUVER-SIDE-RIGHT 017471
17 LOUVER-SIDE-LEFT 028288
18 TRIM-REAR·CORNER·RIGHT 013663
19 SCREW 011694
20 PIN-RETAINER-HOPPER CVR 043934
21 CARRIAGE BOLT 012347
22 PAN-DRIP 048204
*23 TRIM-REAR·CORNER·LEFT 013761
*NOT SHOWN
