Taylor PH71 - Parts List

Section 10 Parts List
45
+ Available Separately
Models PH71/PH84 Parts List
DESCRIPTION PART
NUMBER
PH71
QTY.
PH84
QTY.
WARR.
CLASS
REMARKS PARTS
UPDATE
ADAPTOR A.--CASTER X18915 4 4 103 ACCUMULATOR--GLYCOL (OLD STYLE) 035175 1 1 103 J4019999/PRIOR (SEE TANK) 79
CAP--RADIATOR(OLDSTYLE) 035179 1 1 103 J4019999/PRIOR 79
AGITATOR A. *HT*20 QT HOPPER X44797 1 2 103 BEARING--FRONT 050348 2 000 W/FRONT SHOES (X50350--KIT) BEARING--REAR SHELL *NICK.PLATE 031324 1 2 000
+GUIDE--DRIP SEAL 028992 1 2 000 +NUT--BRASS BEARING 028991 1 2 000 +WASHER--BEARING LOCK 012864 1 2 000
BEATER A.--3.4QT--1 PIN--SUPPORT X46231 1 2 103
+BLADE--SCRAPER--PLASTIC 8--1/8L 046235 2 4 000 +CLIP--SCRAPER BLADE 046236 2 4 103
BELT--AX35 022848 2 000 BELT--AX31 041575 4 000 BELT--RD 3/16W X 4.70 ID 043121 1 000 AGITATOR MOTOR BELT--RD 3/16 W X 4.01 ID 036161 1 000 AGITATOR M OTOR BELT--RD 3/16 W X 9.12 ID 039108 1 000 AGITATOR M OTOR BLOCK--TERMINAL--2 POLE 039422 1 2 103 BLOCK--TERMINAL--5 POLE 024329 1 2 103 BLOCK--TERMINAL--PLUG 10P .2 SIP 040322--005 1 2 103 BLOCK--TERMINAL--PLUG 7P .2 SIP 040322--003 2 4 103 BLOCK--TERMINAL--PLUG 8P .2 SIP 040322--004 1 2 103 BLOWER A. X47833-- 1 1 103 J4090000/UP HP62 86
HOUSING A.--W/WHEEL X30160 1 1 103 MOTOR--BLOWER FAN 230V 046536-- 1 1 103 J4090000/UP HP62 86
BLOWER A. X30153-- 1 1 103 J4089999/PRIOR 86
HOUSING A.--W/WHEEL X30160 1 1 103 MOTOR--BLOWER FAN 230V 030157-- 1 1 103 J4089999/PRIOR 86
BRUSH--DOUBLE ENDED--PUMP&FEED T 013072 1 1 000 BRUSH--DRAW VALVE 1”ODX2”X17”L 013073 1 1 000 BRUSH--END--DOOR--SPOUT--SS--HT 039719 1 1 000 BRUSH--MIX PUMP BODY--3”X7”WHITE 023316 1 1 000 BRUSH--REAR BRG 1IN.DX2IN.LGX14 013071 1 1 000 CABLE--RIBBON--10C--56”L--DIL/DILR 040040--039 1 1 103 J3IFR--LED CABLE--RIBBON--14C--14”L SIP/SIPR 040040--015 1 1 103 J9UC--LCD
