Taylor PH71 - Pump Assembly X45316-B

10
Models PH71/PH84Operator Parts Identification
Pump Assembly X45316--B
PH71
/
PH84
ITEM DESCRIPTION PART NO.
1 TUBE A.-MIX INLET X45318
2 SEAL --AIR INLET FITTING 045327
3 SPRING 022456
4 POPPET 022473
5 BODY A.--COAX VALVE B X46860-B
6 O--RING--PISTON/LVB (3) 020051
7 O--RING--LVB 018664
8 PISTON--COAX B 045319-B
9 PIN A.--COAX PUMP X36950
10 CYLINDER A. --PUMP X44755
ITEM DESCRIPTION PART NO.
11 O--RING--MIX INLET TUBE 015835
12 RING--CHECK --LVB (2) 020050
13 RING-CHECK-LVB 033215
SEPARATE ITEMS:
14 O-RING-FEED TUBE 016132
15 PIN--COTTER--HAIRPIN 044731
16 CLIP--MIX PUMP RETAINER 044641
TUBE A.--PUMP FEED (PH71) X44666
17
TUBE A.--PUMP FEED--L (PH84) X44662
TUBE A.--PUMP FEED--R (PH84) X44664
