Models PH71/PH84 Operating Procedures
140815
Draining Product From The Freezing
Cylinder
Step 1
Press the AUTO key, cancelling compressor and
beater motor operation.
Figure 50
Step 2
Remove the hopper cover and the agitator. Take these
parts to the sink for cleaning.
Step 3
With a pail below the door spout, press the WASH and
PUMP keys. Open the draw valve and drain the
remaining product from the freezing cylinder and mix
hopper.
Figure 51
Step 4
When the flow of product stops, press the WASH and
PUMP keys, and close the draw valve. Discard this
product.
Figure 52
Step 5
Remove the locking clip and the mix feed tube.
Remove the pump clip and the assembled air/mix
pump.
Repeat Steps 1 through 5 for the other side of the
freezer on the Model PH84.
Rinsing
Step 1
Pour two gallons (7.6 liters) of cool, clean water into the
mix hopper . With the white hopper brush, scrub the mix
hopper, mix level sensing probes, the outside of the
agitator drive shaft housing. Using the double ended
brush, clean the mix inlet hole.
Note: Do not brush clean the mix inlet hole while the
machine is in the WASH mode.
Step 2
With a pail beneath the door spout, press the WASH
key.
Figure 53
To Next Page
