15
Models PH71/PH84 Important: To the Operator
(PH84 only). The third line of the display shows the
temperature of the mix hopper . After pressing the
AUTO key, the last line of the display shows the month
and date (MM = month, DD = day) that the machine
needs to be disassembled and brush cleaned.
PH71 Screen:
MODE: OFF
HOPPER TEMP: 40.0F
BRUSH CLEAN ON: MM/DD
PH84 Screen:
OFF :MODE: OFF
OK :MIX: OK
40.0F HOPPER 40.0F
BRUSH CLEAN ON: MM/DD
The next display indicates the freezer is operating in
two different modes. The following information is
given:
The machine is operating in the WASH and PUMP
modes, the temperature of the mix hopper is 40_F
(4.4_C), and the machine needs to be brush cleaned
on October 31st.
PH71 Screen:
MODE: WSH-PMP
HOPPER TEMP: 40.0 F
BRUSH CLEAN ON: 10/31
PH84 Screen:
The next display indicates the freezer is operating in 3
different modes. The following information is given:
The left side of the freezer is operating in the
STANDBY mode, and the mix level in the hopper is
OUT. The right side is operating in the WASH and
PUMP modes, and the mix level in the hopper is LOW.
The temperature of the mix in both hoppers is 40_F.
(4.4_C.), and the machine needs to be brush cleaned
on October 31st.
STANDBY :MODE: WSH--PMP
OUT :MIX: LOW
40.0F HOPPER 40.0F
BRUSH CLEAN ON: 10/31
The following displays pertain to the HEAT cycle:
While in the heating phase, you will see this display. It
shows the present temperature of the hopper .
PH71 Screen:
MODE: HEAT
PHASE: HEAT
HOPPER TEMP: 140.0 F
BRUSH CLEAN ON: MM/DD
PH84 Screen:
HEAT :MODE: HEAT
HEAT :PHASE: HEAT
140.0F HOPPER 140.0F
BRUSH CLEAN ON: MM/DD
The mix temperature must be raised above 151_F
(66.1_C) within 90 minutes or the freezer will be locked
in STANDBY, and the cycle failure display will appear.
In the example, the hopper temperature is 140_F
(60_C). The phase shows that the machine is in the
heat phase of the heat treatment cycle.
When the heating phase is complete, the freezer goes
into the holding phase of the cycle. The holding phase
will hold the temperature above 151_F (66.1_C) for a
minimum of 30 minutes.
In this example, the hopper temperature is 151_ F
(66.1_C).
PH71 Screen:
MODE: HEAT
PHASE: HOLD
HOPPER TEMP: 151.0 F
BRUSH CLEAN ON: MM/DD
PH84 Screen:
HEAT :MODE: HEAT
HOLD :PHASE: HOLD
151.0F HOPPER 151.0F
BRUSH CLEAN ON: MM/DD
