19
Models PH71/PH84 Important: To the Operator
Screen “D” is SYSTEM INFORMATION. The first
screen indicates the software version used in the unit.
SOFTWARE VERSION
PH71 Control UVC2
Version 2.00
SEL
Press the SEL key to view the second screen of the
SYSTEM INFO RMATION display. This screen indi-
cates the language, version number and language
strings used in the unit.
Language
V1.10r00 English 459
SEL
Press the SEL key to view the third screen of the
SYSTEM INFORMATION display. This screen
indicates the Bill of Material number and serial number
of the unit. Press the SEL key once to return to the
OPERATOR MENU.
B.O.M. PH7133B000
S/N K0000000
SEL
Screen “E” is AUTO HEAT TIME. This screen is used
to set the time of day in which the heat treatment cycle
will start. Move the cursor under the number you wish
to change. Press the plus key to increase the number;
press the minus key to decrease the number. When
the desired time appears, press the SEL key once to
return to the OPERATOR MENU.
AUTO HEAT T IME
TIME: 12:00 AM
-- --
<--- ---> +++ -- -- -- SEL
Screen “F” is CURRENT CONDITIONS. This screen
gives the viscosity of the product and the hopper and
barrel temperatures. The last line of the display is the
compressor countdown safety timer. The safety timer
prevents the compressor from running more than 11
minutes (other than during the cooling phase of the
heat treatment cycle).
Press the SEL key once to view the SERVINGS
COUNTER screen.
PH71 Screen:
VISC HOPPER BARREL
0 38.5 28.5
TIME C 11:00 11:00
PH84 Screen:
VISC HOPPER BARREL
0 38.5 28.5
0.0 38.5 18.0
TIME C 11:00 11:00
The SERVINGS COUNTER screen indicates the
number of times the draw switch has closed (number
of draws) since the last brush cleaning or since the last
serving counter reset. A maximum of 32,767 draws
can be recorded; an additional draw will cause the
counter to restart at zero. Pressing the SEL key will
return the display to the OPERATUR MENU.
PH71 Screen:
SERVINGS COUNTER
DRAWS
12
SEL
PH84 Screen:
SERVINGS COUNTER
LEFT RIGHT
12 15
SEL
Draws are counted during the AUTO mode of
operation only.
Screen “G” is HEAT CYCLE DATA. The information
from the previous heat treatment cycles can be
obtained through this screen. The most recent heat
treatment cycle data will be shown first; press the plus
key to scroll through the remaining heat cycle displays.
If a heat treatment cycle failure should occur, a 2
character message will appear on the second line of
the screen. Press the SEL key once to return to the
OPERATOR MENU.
