Taylor PH71 - Page 58

+ Available Separately
54
Parts List Models PH71/PH84
DESCRIPTION PARTS
UPDATE
REMARKSWARR.
CLASS
PH84
QTY.
PH71
QTY.
PART
NUMBER
SLEEVE A.--PUMP X45012 1 103
+NUT--PUMP SLEEVE 036933 1 103
SLEEVE A.--PUMP X44761 2 103
+NUT--PUMP SLEEVE 036933 2 103
STARTER--1 PHASE--4.5 TO 7 AMP 041950--27K 1 2 103 SINGLE PHASE STARTER--3 PHASE--3 TO 5 AMP 041950--33J 1 2 103 THREE PHASE SWITCH A.--DRAW X33322--SER 1 103 SELF CLOSING
ARM A.--DRAW X33326 1 103 BRACKET A.--SWITCH X43722 1 103 CLIP--HAIRPIN .026 WIRE 37/64L 014051 1 000 NUT--4--40 HEX --PLATED-- 038623 2 000 PIN--PIVOT 015478 1 103 SCREW--4--40 X 5/8 RHM--ZP STEEL 027219 2 000 SPRING--RETURN--LEFT--SELF CLOSE 041660 1 103 SPRING--RETURN--RIGHT--SELF CLOSE 041661 1 103 SWITCH--LEVER--SPDT--10A--125--250V 028889 1 103
SWITCH A.--DRAW X38547 1 103 SELF CLOSING
ARM--SWITCH--DRAW--LEFT 038649 1 103 ARM--SWITCH--DRAW--RIGHT 038650 1 103 BRACKET A.--SPRING RETURN X38257 1 103 BRACKET A.--SWITCH *338--39--754 X38252 1 103 E--RING 1/4 032190 4 000 PIN--PIVOT--DRAW SWITCH 038484 1 103 ROD--SPRING RETAINER 038254 1 103 SCREW--8--32X3/8 HEX HD TYPE 23 039267 2 000 SPRING--EXTENSION.375X.045X1.00 038922 2 103 SPRING--RETURN--LEFT--TWIN TWIST 038923 1 103 SPRING--RETURN--RIGHT--TWIN TWIST 038924 1 103 SWITCH A.--DRAW--TWIN TWIST X39269 1 103
BRACKET--DRAW SWITCH--TWIN TWIST 039264 1 103 SCREW--4--40 X1/2 042604 4 000 SWITCH--LEVER--SPDT--11A--125--25 039252 2 103
SWITCH--MEMBRANE-- 5 POSITION-- 8”L 044520 1 1 103 SWITCH -- MEMBRANE --5 POSITION -- 20” 044521 1 103 SWITCH--PRESSURE 440PSI 048230 1 2 103 J4090000/UP (REPLACES 046362) 86 & 119 SWITCH--PRESSURE 25PS OPEN 405 030886 1 2 103 J4089999/PRIOR 86
