Models PH71/PH84 Operator Parts Identification
PH71 Parts Id en t ificatio n
ITEM DESCRIPTION PART NO.
1 COVER-HOPPER 053809
2 PANEL A.-LOWER SIDE X39075 -SER
3 AGITATOR A. *HT*20 QT. X44797
4 PANEL -UPPER·SIDE-LEFT 024426
5 STUD-NOSE CONE 022822
6 PANEL -REAR 048203
7 PANEL -UPPER SIDE RIGHT 028823
8 PAN-DRIP 11 -5/8 LONG 027503
9 PANEL A.-LOWER SIDE X24424 -SER
10 ADAPTOR A.-CASTER X18915
11 PANEL-SERVICE 045637
ITEM DESCRIPTION PART NO.
12 TRAY-DRIP 14.8 046275
13 SHIELD -SPLASH-WIRE 046177
14 PANEL A.-FRONT X45630
15 CASTER-SWV 5/8 STEM 4IN 018794
16 SCREW 011694
17 CARRIAGE BOLT 012347
18 TRIM-REAR CORNER-RIGHT 046391
19 LOUVER SIDE -R&L 017471
20 PIN-RETAINER-HOPPER CVR 043934
21 PAN-DRIP 048435
*22 TRIM-REAR CORNER-LEFT 046390
*NOT SHOWN
