Model R280
User Function Menu Structure
• Use the Up and Down arrow buttons to find the desired function.
• Press the Enter button to select the desired function.
• Basket Size buttons also function as numbers:
(Left Small=1, Left Medium=2, Left Large=3, Right Small=4, Right Medium=5, Right Large=6)
Note: If a password has been set, there is a Service Password available to access both the Manager Menu and
Diagnostic Menu. The Service Password is 22463†.
User Functions Function Name Description
Main Screen Main Screen Default condition of the display. Live temperature, error display, and
hopper status (full/empty).
U1 Last Basket/Cancel Selections Halts weighing-in process. Turns off all size button lights.
Immediate return to Main screen.
U2 Calibrate Scales
Note: See Calibrations and
Adjustments on page 29.
1. Request side to calibrate. Display reads: “[CAL]” or “---” when set
to metric units, with alternating flashing brackets. Use Basket size
button to select side.
2. Waits for a basket to be placed for the side to be calibrated then
empties the accumulator doors into the basket. The display will
read “[ -- “ (“ -- ]”) until a basket is presented.
3. Remove hopper for side to be calibrated. NOTE: Leave the
housing in place on the accumulator doors.
4. Tares automatically. Display reads “[ 0.0 “ (“ 0.0 ]”)
5. Waits for 1.0 lb. reference. Display reads “[ 1.0 “ (“ 1.0 ]”), or
“[450” (“450]”) when set to metric units. Place 1.0 lb. (450 g)
weight on the accumulator doors.
6. Waits for 2.0 lb. reference. Display reads “[ 2.0 “ (“ 2.0 ]”), or “[900”
(“900]”) when set to metric units. Place 2.0 lb. (900 g) weight on
the accumulator doors.
7. Waits for weight removal. Display will read “ --- “ Remove
weight(s) from the accumulator doors.
8. Re-install hopper.
9. The Dispenser will return to normal operation with no basket size
selected on affected side.
