Model R280
Introduction
This Model R280 Frozen Food Dispenser is a
refrigerated unit that dispenses frozen fries.
It is recommended that these operating procedures be
followed closely to ensure correct assembly and
disassembly of the Dispenser.
Unpacking and Installation
Remove all packing material from Dispenser. Open
cabinet door. Disassemble, clean, sanitize, and dry the
hopper and accumulator assemblies. Clean, sanitize,
and dry fry baskets. See
Disassembly, Defrost, and
Cleaning on page 8. Reassemble all components, see
Dispenser Assembly on page 6.
Intended Use
The Frozen Food Dispenser is intended to maintain and
dispense frozen fries from two independent hoppers.
Each is capable of dispensing different volumes of fries.
All product should be removed daily for cleaning and
maintenance of the Dispenser. The performance of the
system requires that recommended procedures for
storage and use of the dispensed product be followed
closely.
HAZARD COMMUNICATION STANDARD (HCS):
The procedure(s) in this manual include the use of
chemical products. These chemical products will be
highlighted with bold faced letters followed by the
abbreviation (HCS) in the text portion of the procedure.
See the Hazard Communication Standard (HCS) manual
for the appropriate Material Safety Data Sheet(s)
(MSDS).
Specifications
Electrical Requirements:
Domestic:
• 120V, 60 Hz, 8A, 1 Phase
International:
• 220–240V, 50Hz, 4.6A, 1 Phase
• 220–240V, 60Hz, 4.6A, 1 Phase
Internal Circuit Breaker:
•15A
Dimensions:
• Width 28.5 in. (73 cm)
• Depth 32 in. (81 cm)
• Height 74.75 in. (190 cm)
Recommended Operating Dimensions:
• Width 30.5 in. (78 cm)
• Depth 32 in. (81 cm)
• Height 74.75 in. (190 cm)
Weight:
• Net 409 lb. (186 kg)
• Crated 472 lb. (214 kg)
Note: For reference only.
Hopper Capacity:
• 60 lb. (27 kg)
• 30 lb. (13 kg) per hopper
Note: Weight may vary with product.
Operating Temperature:
• -2°F to 10°F (-19°C to -12°C)
Note: (Recommended ambient operating
temperature of 75°F [24°C])
• ST (Subtropical)
Refrigeration:
Domestic:
• Model R280, R290 (5.15 oz.) (146 g)
International:
• Model R280, R290 (5.15 oz) (146 g)
Insulation Blowing Gas:
• HFO-1233ZD and HFO-1234ZE
Maximum Operating Altitude and Safe Tilt:
• Maximum Altitude: 6,561 ft. (2,000 m)
Maximum Tilt = 10°
Noise Emissions:
• < 70 dB (A)
FCC Statement:
WARNING This equipment generates, uses,
and can radiate radio frequency energy and, if not
installed and used in accordance with the instruction
manual, may cause interference to radio
communications.
