46
Model R280
Wiring Harnesses (Not Pictured)
Note: Contact Taylor to verify lengths.
* Not shown.
Item Part No. Description Qty.
* 293406 120/220 VAC Harness (Rev F and later) 1
* 380052 120/220 VAC Harness (Rev A through E) 1
* 293408 DC Power Harness (Power supply to Control Board) 1
* 294011 Motor Control Harness (Rev F and later) 1
* 380053 Motor Control Harness (Rev A through E) 1
* 294108 Harness, ON/OFF Switch 1
* 293407 Relay Control Harness 1
* 293409 AC Power Harness (Power Supply to Terminal Block) 1
* 293333-12 Wire-Heater-Door-Cab *R280* 1
* 294262-27 Wire-Heater-Door-Cab*R280* INTL 1
