Taylor R280 User Manual

32
Model R280
Parts Identification
Front View
Figure-17
*Not Shown
1
2
4
3
5
6
10
9
8
7
Item Part No. Description Qty.
1 089350
600132
Keypad-Membrane
Screw-6-32x1/2 PHL Pan 18-8 SS
1
6
2 292246 ON/OFF Switch (15A Circuit
Breaker)
1
3 295964
293189
Door Assembly w/ gasket
Door Gasket
1
1
4 293706
293855
Hinge, Door
Screw Truss Head Phillips
3/8-16x1/2”
2
4
5 295499
295578
295639
078521
Support Bar RH
Support Bar LH
Tray Support Bar
Screw Truss Head Machine Slotted
18-8 Stainless Steel 1/4-20 x 3/4 In.
1
1
1
10
6 295674
295675
294022
294147
290687
294021
058317
Right Basket Tray
Left Basket Tray
Right Basket Tray (used before
Serial # LONR1302E04090)
Left Basket Tray (used before Serial
# LONR1302E04090)
Locator Pin
Guide Bar
Screw-10-32x3/8 SLTD Truss
1
1
1
1
4
2
4
7 294821
293590
Drip Tray (with extended front)
Drip Tray
1
8 294749
291158
294803
294800
077865
293512
Panel, Filter Access, Louvered
Screw, Thumb
Retainer, Thumb Screw
Nut, Nylon, Spacer
Nut, Hex Nylon Insert 18-8 SS
5/16-18
Filter, Condenser
1
2
2
2
4
1
9 216596
200766
200774
Caster, Front Locking
Screw, Hex-Head 5/16-18x 1”
Screw, Hex-Head 5/16-18x3/4”
2
4
4
10 216595
200774
Caster, Rear
Screw, Hex-Head 5/16-18x3/4”
2
8
* 291050
294008
Basket, Fry, Black Handle
Case of 8 Fry Baskets
* 294410 Label Kit 1
