Taylor R280 User Manual

19
Model R280
d09 Actuate Outputs
Basket Size buttons also function as
numbers
The refrigeration circuit contains
anti-short-cycle protection.
Allows outputs to be turned on and off to aid in diagnosing problems.
Display shows selected motor and command (e.g. “d2 on” indicates
the right drum motor’s output is on.)
Use Basket Size buttons to select an output:
1. Left drum motor (d1)--Left Small Basket
2. Left accumulator motor (A1)--Left Medium Basket
3. Right drum motor (d2)--Right Small Basket
4. Right accumulator motor (A2)--Right Medium Basket
5. Refrigeration compressor (rF)--right large basket Up arrow turns
output on,
Down arrow turns output off.
Enter button closes function.
The display flashing “rF OFF” indicates the refrigeration compressor
cannot be restarted until the 2-minute short cycle delay is met.
All outputs will turn off and return to normal operation when exiting the
function.
d10 Diagnostics Display
Note: See Using the Diagnostic
Display (D10) on page 24.
Shows status of all controller Inputs and outputs while the Dispenser
continues normal operation.
Display shows all activated Inputs and outputs. (See Using the
Diagnostic Display (D10) on page 24.)
Size and Enter buttons function just as in Main screen during
normal operation.
Up arrow button does nothing.
Down arrow button will exit the function
d11 Bypass Basket Sensors
Note: Volatile setting (will reset
each time power is cycled).
Allows the Dispenser to be used when a basket sensor has failed.
Display will read “[bYP]” with alternating flashing brackets.
Use Basket Size buttons to select the side to be bypassed.
Display will default to the current sensor condition.
Up arrow sets bypass mode. “[ YES” ( “YES]”)
Down arrow clears it. “[ no” (“ no]”)
Enter button executes selection, exits function, and returns to d01.
d12 Bypass Weighing
Note: Volatile setting.
Disable the scale to allow other diagnostics to be performed without
wasting product.
Display will read “[SCL]” with alternating flashing brackets.
Use Size keys to select the side to be bypassed.
Display will default to current scale status.
Up arrow turns the scale on for selected side “[ on” (“ on ]”).
Down arrow turns off the scale
or selected side. “[ OFF” (“ OFF ]”).
Enter button executes selection, exits function, and returns to d01.
Diagnostic
Functions
Function Name Description
