Taylor R280 User Manual

41
Model R280
Weighing System Assembly (Cont.)
(After and Including Serial Numbers LONR and 28PR)
Item Part No. Description Qty.
23 293323 Link, Accumulator, Push 1
24 290635 Screw, Shoulder, #10-24, 1/4" x 1/4" 2
25 204761 Nut Nylon Lock Hex 18-8 SS 5/16-
18
2
26 293325 Washer, Spacer, 0.25" ID x 0.12" 2
27 Pin, Clevis (Available in kit 294693) 1
28 310139 Retaining Ring, E-Style, 1/4" 1
29 294693 Kit, Drive Wheel 1
30 290295 Set Screw, 1/4-20 x 0.375" 1
31 293384 Spring, Extension 1
Item Part No. Description Qty.
32 293390 Bracket, Spring Base 1
33 213262 Screw-Socket Head Cap #10-32 x3/8" 1
34 Magnet (Available in Kit 380049 only) 1
35 380049 Kit, Block, Magnet Mount (includes
Magnet)
1
36 213139 Washer, Flat, #10 1
37 213136 Screw, Socket Head Cap, #10-32 x 1-
1/4"
2
38 293596 Collar, Accumulator Shaft, White 4
39 203257 O-ring 11/16 In OD x1/2 In ID x3/32 In. 4
