6. STEERING SYSTEM
- 95 -
Fig. 6.32
Fig. 6.33
Fig. 6.34
⑨
Remove the set plate. Pull out the sensor
housing assembly, taking caution not to lose the
spring.
Then remove the thrust washer, needle bearing,
and thrust washer.
⑩
Remove the bolt securing the side cover.
Remove the side cover and sector shaft as one
unit.
⑪
Remove the bolt securing the rear cover.
Remove the rear cover and the warm shaft.
