TCM FB30-7 - Page 152

8. LOAD HANDLING SYSTEM
- 140 -
Fig. 8.7 Locations of Rollers (2- to 3.0-ton Trucks)
LIFT CYLINDER
OUTER CHANNEL
INNER CHANNEL
SIDE ROLLER (adjust with shims)
CARRIAGE
END ROLLER (adjust with shims)
SLIPPER (adjust with shims)
Upper section Lower section
END ROLLER (adjust with shims)
END ROLLER (adjust with shims)
END ROLLER (adjust with shims)
