TCM FB30-7 - Page 153

8. LOAD HANDLING SYSTEM
- 141 -
END ROLLER
END ROLLER
SIDE ROLLER
(adjust with shims)
OUTER CHANNEL
INNER CHANNEL
SLIPPER
(adjust with shims)
SIDE ROLLER (adjust with shims)
END ROLLER
SIDE ROLLER (adjust with shims)
INNER CHANNEL
SIDE ROLLER (adjust with shims)
END ROLLER
OUTER CHANNEL
RETAINING ROLLER
RETAINING ROLLER
Fig. 8.8 Locations of Rollers (3.5-ton Trucks)
Upper section Lower section
