TCM FB30-7 - Page 5

No. SEB-81BBE
SPECIFICATIONS (1)
Model
FB10-7 FB15-7 FB18-7
Item
Performance
Max. load kg [lbf]
1000 [2000] 1500 [3000] 1750 [3500]
Load center mm [in.] 500 [24] ← ←
Max. lifting height mm [in.] 3000 [118.1] ← ←
Tilting angle
Fwd ° 6 ← ←
Bwd ° 12 ← ←
Free lift A mm [in.] 150 [5.9] 155 [6.1] ←
Mast tilting time (Fwd - Bwd) s 2.0 - 1.4 ← ←
Fork lifting speed
Loaded mm/s [fpm] 390 [76.8] 350 [68.9] 330 [65.0]
Unloaded mm/s [fpm] 580 [114.2] ← ←
Travel speed
Loaded km/h [mph] 14 [8.7] ← 13 [8.1]
Unloaded km/h [mph] 16 [9.9] ← ←
Gradeability
(Starting on an uphill when loaded) 1/7 ← ←
Min. turning radius
(Outermost part of truck) B mm [in.] 1700 [66.9] ← 1790 [70.5]
Min. intersecting aisle mm [in.] 1690 [66.5] ← 1730 [68.1]
Dimensions
Overall length (includ. fork) C mm [in.] 2875 [113.2] ← 2975 [117.1]
Overall width D mm [in.] 1070 [42.1] ← ←
Overall height (Overhead guard) E mm [in.] 2050 [80.7] ← ←
Overall extended height mm [in.] 4030 [158.7] ← ←
Wheel base F mm [in.] 1250 [49.2] ← 1350 [53.1]
Tread
Front wheels G mm [in.] 910 [35.8] ← ←
Rear wheels H mm [in.] 900 [35.4] ← ←
Fork overhang J mm [in.] 375 [14.8] ← ←
Rear overhang K mm [in.] 330 [13.0] ← ←
Fork size
(Length L x Width M x Thickness N) mm [in.] 920 x 100 x 35 ← ←
[36.2 x 3.9 x 1.4]
Fork spacing P mm [in.] 200 - 920 [7.9 - 36.2] ← ←
Minimum under clearance Q mm [in.] 95 [3.7] (Frame) ← ←
Tow pin height mm [in.] 390 [15.4] ← ←
Weight
Service Weight with std. batteries kg [lbf] 2650 [5842] 2710 [5976] 3000 [6600]
The values in the Performance section are given for the trucks in the Super mode.
