No. SEB-81BBE
SPECIFICATIONS (2)
Model
FB20-7 FB25-7
FB25-7LB
Item FB25-7V
Performance
Max. load kg [lbf] 2000 [4000] 2500 [5000] ←
Load center mm [in.] 500 [24] ← ←
Max. lifting height mm [in.] 3000 [118.1] ← ←
Tilting angle
Fwd ° 6 ← ←
Bwd ° 12 ← ←
Free lift A mm [in.] 160 [6.3] ← ←
Mast tilting time (Fwd - Bwd) s 2.7 - 2.0 ← ←
Fork lifting speed
Loaded mm/s [fpm] 290 [57.1] 255 [50.2] ←
Unloaded mm/s [fpm] 510 [100.4] ← ←
Travel speed
Loaded km/h [mph] 13.5 [8.4] ← 13 [8.1]
Unloaded km/h [mph] 15 [9.3] ← 14.5 [9.0]
Gradeability
(Starting on an uphill when loaded) 1/7 ← 1/8
Min. turning radius
(Outermost part of truck) B mm [in.] 1950 [76.8] 1970 [77.6] 2065 [81.3]
Min. intersecting aisle mm [in.] 1895 [79.6] 1905 [75.0] 1955 [76.9]
Dimensions
Overall length (includ. fork) C mm [in.] 3315 [130.5] 3355 [132] 3460 [136]
Overall width D mm [in.] 1150 [45.3] ← ←
Overall height (Overhead guard) E mm [in.] 2095 [82.5] ← LB: 2250 [88.6]
V : 2100 [82.7]
Overall extended height mm [in.] 4030 [158.7] ← ←
Wheel base F mm [in.] 1400 [55.1] ← 1545 [60.8]
Tread
Front wheels G mm [in.] 955 [37.6] ← ←
Rear wheels H mm [in.] 950 [37.4] ← ←
Fork overhang J mm [in.] 435 [17.1] ← ←
Rear overhang K mm [in.] 410 [16.1] 450 [17.7] 410 [16.1]
Fork size
(Length L x Width M x Thickness N)
mm [in.] 1070 x 122 x 40 ← ←
[42.1 x 4.8 x 1.6]
Fork spacing P mm [in.]
245 – 1020 [9.6 – 40.2] ← ←
Minimum under clearance Q mm [in.] 100 [3.9] (Front axle) ← ←
Tow pin height mm [in.] 440 [17.3] ← ←
Weight
Service Weight with std. batteries kg [lbf] 3470 [7650] 3850 [8489] LB: 4350 [9592]
V : 4250 [9371]
The values in the Performance section are given for the trucks in the Super mode.
