TCM FB30-7 - Page 7

No. SEB-81BBE
SPECIFICATIONS (3)
Model FB30-7
FB35-7S
Item FB30-7V
Performance
Max. load kg [lbf]
3000 [6000] 3500 [7000]
Load center mm [in.] 500 [24] ←
Max. lifting height mm [in.] 3000 [118.1] ←
Tilting angle
Fwd ° 6 ←
Bwd ° 12 10
Free lift A mm [in.] 165 [6.5] 150 [5.9]
Mast tilting time (Fwd - Bwd) s 2 - 2 ←
Fork lifting speed
Loaded mm/s [fpm] 290 [57.1] 230 [45.3]
Unloaded mm/s [fpm] 490 [96.5] 400 [78.7]
Travel speed
Loaded km/h [mph] 13.5 [8.4] 12.5 [7.8]
Unloaded km/h [mph] 15 [9.3] 14 [8.7]
Gradeability
(Starting on an uphill when loaded) 1/8 ←
Min. turning radius
(Outermost part of truck) B mm [in.] 2140 [84.3] 2360 [92.9]
Min. intersecting aisle mm [in.] 2050 [80.7] 2250 [88.6]
Dimensions
Overall length (includ. fork) C mm [in.] 3580 [141] 3835 [151.0]
Overall width D mm [in.] 1225 [48.2] 1380 [54.3]
Overall height (Overhead guard) E mm [in.] 2190 [86.2] ←
V: 2100 [82.7]
Overall extended height mm [in.] 4260 [167.7] 4265 [167.9]
Wheel base F mm [in.] 1600 [63.0] 1800 [70.9]
Tread
Front wheels G mm [in.] 1000 [39.4] 1140 [44.9]
Rear wheels H mm [in.] 950 [37.4] ←
Fork overhang J mm [in.] 480 [18.9] 530 [20.9]
Rear overhang K mm [in.] 430 [16.9] ←
Fork size
(Length L x Width M x Thickness N) mm [in.] 1070 x 125 x 45 1070 x 150 x 50
[42.1 x 4.9 x 1.8] [42.1 x 5.9 x 2.0]
Fork spacing P mm [in.] 250 – 1090 [9.8 – 42.9] 300 – 1200 [11.8 – 47.2]
Minimum under clearance Q mm [in.] 110 [4.3] (Rear axle) ←
Tow pin height mm [in.] 475 [18.7] ←
Weight
Service Weight with std. batteries kg [lbf] 4660 [10275] 5590 [12325]
The values in the Performance section are given for the trucks in the Super mode.
