3. CONTROL SYSTEM
- 38 -
■ Checking procedure by error code
(1) Traveling system
No.
01
[ 303]
05
[ 303]
06
[ 303]
02
[ 304]
13
[ 304]
14
[ 304]
15
[ 304]
03
[ 305]
04
[ 306]
07
[ 501]
16
[ 501]
Problem
Traveling power module
shorted
Traveling power
module’s upper FET is
short-circuited
Traveling power
module’s lower FET is
short-circuited
Traveling power module
is open.
Traveling power
module’s phase “U” is
open .
Traveling power
module’s phase “V” is
open.
Traveling power
module’s phase “W” is
open.
Traveling contactor
(MD)shortedorsensor
circuit harness defective
Traveling contactor
(MD)isstuckopenor
sensor circuit harness is
defective
Traveling contactor
(MD)driveTris
defective (Tr3 on
CPU board), traveling
contactor coil is stuck
open or sensor circuit
harness is defective.
Fwd or Rev direction
switch is defective.
Error
The truck won’t move.
(MDcontactordoesnot
close.)
(Traveling quick charge
error: error code 69)
(Occurrence is also
detected.)
Truck won’t move.
The truck won’t move.
The truck won’t move.
The truck won’t move.
The truck won’t move.
Remedy
Proceed with remedy in numerical order of encircled numbers.
①Checktravelingpowermodules(TMDU,
TMDV,TMDW)andchangeifneeded.
(When changing any power module, change
the power supply board, too.)
② Check harness between CN3R (power supply
board) and each power module, and repair or
change if needed.
③ Check harness between CN4-2 (CPU board)
and P3 terminal, and repair or change if
needed.
④ Check harness between CN4-8 (CPU board)
and P1 terminal, and repair or change if
needed.
⑤ If no defect is found throughout the above
steps, change power supply board.
① Check harness between CN2R (power supply
board) and CN8 (CPU board), and repair or
change if needed.
②Checktravelingpowermodules(TMDU,
TMDV,TMDW),andrepairorchangeif
needed. When changing any defective power
module, change power supply board, too.
③ Check harness between CN3R (power supply
board) and each power module, and repair or
change if needed.
④ Check harness between CN4-2 (CPU board)
and P3 terminal, and repair or change if
needed.
⑤ Check harness between CN4-8 (CPU board)
and P1 terminal, and repair or change if
needed.
⑥ If no defect is found throughout the above
steps, change power supply board.
①Checktravelingcontactor(MD)(forwelding
or mechanical hitch) and repair or change if
needed.
② Check harness between CN5-11 (CPU board)
and P2 terminal, and repair or change if
needed.
③ Check harness between CN4-2 (CPU board)
and P3 terminal, and repair or change if
needed.
①Checktravelingcontactor(MD)(forforeign
matter between contact points or mechanical
hitch) and repair or change if needed.
② Check harness between CN5-11 (CPU board)
and P2 terminal, and repair or change if
needed.
③ Check harness between CN4-2 (CPU board)
and P3 terminal, and repair or change if
needed.
①Checktravelingcontactor(MD)coilfor
disengagement of connectors or broken coil,
and repair or change if needed.
② Check harness between contactor oil connector
and CN4-4,12 (CPU board), and repair or
change if needed.
③ Change CPU board (drive Tr defective).
① Check for a shorted harness between CN1-8,21
(CPU board) and FR switch, and repair or
change if needed.
② Repair or change F/R switch.
Reset
Turn off the
key switch.
Turn off
key switch.
Turn off
key switch.
Turn off
key switch.
Turn off
key switch.
Restore to
normal.
Remarks
If any power module is
shorted, the capacitor
between P and N cannot
be charged and thus the
error code 69 is issued.
Both fwd and rev switch
turn of simultaneously.
Numbers in brackets are error codes that appear on the meter panel.
