3. CONTROL SYSTEM
(3) Checking embedded temperature sensor
TheU-phase powermodule(TMDU)andloadhandlingpowermodule (TMP)havetemperature
sensors embedded to monitor the temperature of the power module.
When the temperature sensor detects an abnormal temperature of the module, the output current is
restricted.
① Remove the temperature sensor connectors (THD, THP).
② Set the tester to a resistance range of 1000 Ω and measure the resistance between terminals
according to the table given below.
③  Judgewhetherthemoduleisdefectiveornot,usingthemeasuredvaluesofresistance.
Location
Tester Normal value
(+) (–) Rough guide
THD THD-1 THD-2 0°C: approx. 66 kΩ, 10°C: approx. 40 kΩ
THP THP-1 THP-2 20°C: approx. 25 kΩ, 30°C: approx. 16 kΩ
(4) Replacing heat-dissipating insulation sheet
Theheat-dissipatinginsulationsheetisplacedbetweentheFETpowermoduleandaluminumnto
provideelectricalinsulation,whiletransmittinggeneratedheattothealuminumnefciently.
When replacing the FET power module, make sure to change the insulation sheet with a new one,
too.
The heat-dissipating insulation sheet has a low thermal resistance. It is so thin and fragile that due
caution should be taken when handling. If any damage or cracks are found on it, do not use.
Before installing a new heat-dissipating insulation sheet, make sure the aluminum base, power
module, and insulation sheet are free from metallic powder, cuttings, scores or burrs.
A heat-dissipating insulation sheet which has scores or cracks will lead to a poor insulation
performance, thus causing a shorted FET power module and ground fault.
Wheninstallinganewheat-dissipatinginsulationsheet,alignthecenterofthettingholeoftheFET
module with the center of the hole in the sheet and tighten with care.
