TDE MACNO DVS200 - Parameters Reading Extension

User Manual Chapter 7 - Parameters Description  123
H.040 Progress
It is the indication in percentage of the progress about the Save parameters function.
A displaying of 100% means that the function has been completed.
Code Name [Code] & Function. Default MIN MAX Unit Variation IPA
H.034 0 0 65535 1042
H.040 0 0 100 1009
Parameters Reading Extension
When used a high conversion factor (P. 6 0 0 ), the speed parameters reading must not exceed the values included between
+32767 and 32767.
Over this threshold, it is possible to monitor the variables through this parameters, whose structure allows a reading
extension structure at 32 bits.
H.050 Drive output frequency 16 bit low (d.000)
H.051 Drive output frequency 16 bit high (d.000)
H.052 Drive reference frequency 16 low (d.001)
H.053 Drive reference frequency 16 high (d.001)
H.054 Output speed (d.000)*(P.600) 16 bit low (d.007)
H.055 Output speed (d.000)*(P600) 16 bit high (d.007)
H.056 Speed Ref (d.001)*(P.600) 16 bit low (d.008)
H.057 Speed Ref (d.001)*(P.600) 16 bit high (d.008)
Code Name [Code] & Function. Default MIN MAX Unit Variation IPA
H.050 0 - 2 31 2 31 -1 1010
H.051 0 - 2 31 2 31 -1 1011
H.052 0 - 2 31 2 31 -1 1012
H.053 0 - 2 31 2 31 -1 1013
H.054 0 - 2 31 2 31 -1 1014
H.055 0 - 2 31 2 31 -1 1015
H.056 0 - 2 31 2 31 -1 1016
H.057 0 - 2 31 2 31 -1 1017
