6.5 Quick setup
NOTA!
See section 7.3 later in this manual for further information on enabling the automatic voltage boost function (S.400)
and setting motor slip compensation (S.450 & S.451), .
Step
Setup sequence
Go to the S - Startup menu
Set drive mains voltage
Set drive mains frequency
Set maximum drive output voltage
Set nominal frequency of motor
Set nominal current of motor
Set number of motor terminal pairs
Set the power factor of the motor
Set control mode
Set the maximum reference frequency
Set the reference source
Set drive acceleration and deceleration
ramp times
Set % manual voltage boost
Auto-calibrate motor stator resistance
Save parameters
What to do
Press the "M" key to access the Startup menu.
Got to parameter S.000 and enter the drives mains voltage: 220V
or 240V.
Go to parameter S.001 and enter the drives mains frequency: 50Hz
or 60Hz.
Go to parameter S.100 and enter the maximum voltage the drive
can output to the motor (see data plate).
Go to parameter S.101 and enter the nominal frequency of the
motor (see date plate).
Go to parameter S.150 and enter the nominal current of the motor
(seedata plate).
Go to parameter S.151 and enter the number of motor terminal
pairs (terminals/2).
Go to parameter S.152 and enter the motors power factor (cos phi)
(see data plate).
Go to parameter S.200 and enter the drives control mode:
- selection [1] = START&STOP via terminals (default)
- selection [2] = START&STOP via serial line [see menu H]
Go to parameter S.201 and enter the maximum threshold for the
drives reference frequency (analog and/or digital).
Go to parameter S.202 and enter the source of the drives frequency
reference:
- selection [1] = Reference from analog input 1 (default)
- selection [3] = Digital reference from parameter S.203
NOTE! Go to parameter S.203 and enter the digital reference
frequency (if relevant).
Go to parameter S.300 and enter the acceleration ramp time
(default = 5 secs).
Go to parameter S.301 and enter the deceleration ramp time
(default = 5 secs).
Go to parameter S.400 and enter the % of manual low speed
voltage boost (if relevant)
Go to parameter S.900 and activate the procedure for auto-
calibrating motor stator resistance:
- activate the procedure with "do" + E
Go to the parameter S.901 and activate the procedure for saving
parameters in the drives non-volatile memory.

"
!
$
#
&
%

'


!
"
#
