TDE MACNO DVS200 - 5.2 The power section

24  Chapter 5 - Electrical Connections User Manual
5.2. The power section
Table 5.2.1.1: Power terminal identification and functions
TERMINAL
L2
L1
PE
PE
W
V
U
FUNCTION
BOTTOM
TOP
THREE PHASE POWER TO
MOTOR
GROUND CONNECTION
230 V SINGLE PHASE MAINS
POWER
GROUND CONNECTION
5.2.2 Power terminal wire cross sections
size 025 037 055 075 025 037 055 075
L1, L2
PE
PE
U, V, W 1,5 2,5
1,5 2,5
1,5 2,5
1,5 2,5
Minimum section
[mm
2
]
Maximum section
[mm
2
]
NOTA!
Use only copper wire rated for 75°C.
If the output of a DVS drive short circuits to ground, current in the motors ground wire may reach
up to twice nominal current I
2N
.
