3.1.2. Drive identification
The drives basic technical details are shown in its identification and on its data plate. Example:
DVS - 025
Drive series
Motor power
Drive series
Input power
Output power
Software
Serial interface
EMC filter
DVS
220Vac- 1 phase
025=250W - 037=370W - 055=550W - 075=750W
Standard
Rs485
On board
Choose a drive to suit the nominal current of the controlled motor. The drives nominal output current must be equal to or
greater than that required by the controlled motor.
The speed of an asynchronous motor depends on the number or terminal pairs it has and on its operating frequency (as
specified on the data plate and in the catalogue). If a motor has to be run above its nominal speed, consult the manufacturers
technical service to ascertain what mechanical problems may be incurred (bearing wear, balancing problems, etc.). Also
contact the manufacturers technical service to ascertain what thermal problems may be incurred if the motor has to be run
at a frequency below approximately 20 Hz (e.g. insufficient cooling if no auxiliary ventilation is provided).
3.1.3. Data plate
Check that the specifications on the drives data plate correspond to the original order.
DVS - 075
made in Italy
Load specifications
Input specifications
Drive series
_
AC 220V-15% / 240V +10%
8A 50/60Hz 1PHASE
AC 0 / 230V 3,9A 0,1 / 500 Hz
0,75 kW AC 3Ph MOTOR
MODEL
OPTION
S/N
INPUT
OUTPUT
LOAD
CE
Pollution degree
20
IP
_
