User Manual Chapter 7 - Parameters Description  45
IPA
CODE NAME
PARAMETER PICK LIST
DESCRIPTION
[CODE]
FUNCTION
DESCRIPTION
DEFAULT
MIN
MAX
UNIT
VARIATION
I.100 Dig output 1 cfg Digital Output 1 configura-
tion
[0] Drive Ready
[1] Alarm state
[2] Not in alarm
[3] Motor running
[4] Motor stopped
[5] REV rotation
[6] Steady state
[7] Ramping
[8] UV running
[9] Out trq>thr
[10] Current lim
[11] DC-link lim
[12] Limit active
[13] Autocapt run
[14] Reserved
[15] Neg pwrfact
[16] PID err ><
[17] PID err>thr
[18] PID err<thr
[19] PIDer><(inh)
[20] PIDerr>(inh)
[21] PIDerr<(inh)
[22]
[23]
[24]
[25]
[26] Extern fault
[27] No ext fault
[28] Serial TO
[29] freq=thr1
[30] freq!=thr1
[31] freq>thr1
[32] freq<thr1
[33] freq=thr2
[34] freq!=thr2
[35] freq>thr2
[36] freq<thr2
[37] HS temp=thr
[38] HS temp!=thr
[39] HS temp>thr
Drive ready to start
Positive logic for alarm
signalling
Negative logic for alarm
signalling
Run command active
Run command not active
and frequency = 0Hz
Anti-clockwise rotation of
the motor.
Motor is running in steady
state.
Acceleration or
Deceleration Ramp on
progress.
Undervoltage detectetion
during motor running.
Output torque higher than
the value of P.241.
Current limit (during ramp
or at steady state).
DC Bus limit (during ramp
or at steady state).
General signalling of drive
limit condition.
Autocapture on progress.
Reserved.
Negative condition of the
power factor .
PID error is >A.058 &
<=A.059.
PID error is >A.058.
PID error is <=A.059.
PID error is >A.058 &
<=A.059 (see chapter 7.7).
PID error is >A.058 (see
chapter 7.7).
PID error is <=A.059 (see
chapter 7.7).
Positive logic for Ext. fault
alarm signalling.
Negative logic for Extern.
fault alarm signalling.
Serial link communication
time out.
Output frequency = to
P.440 & P.441 values.
Output frequency ? of
P.440 & P.441 values.
Output frequency > than
P.440 & P.441 values.
Output frequency < than
P.440 & P.441 values.
Output frequency = to
P.442 & P.443 values.
Output frequency ? of
P.442 & P.443 values.
Output frequency > than
P.442 & P.443 values.
Output frequency < than
P.442 & P.443 values.
Heatsink temp = to P.480
& P.481 values.
Heatsink temp ? of P.480
& P.481 values.
Heatsink temp > than
0045 112
Digital Output State Regulation Board
