User Manual Chapter 7 - Parameters Description 75
I.310 = 2 ANY SELECTION (programmed on analog output 2)
Analog output 1 signal proportional to the OUTPUT FREQUENCY of the drive
Analog output 2 signal proportional to the setting of H.021
H.021: + 32767 output = +10V
H.021: - 32767 output = - 10V
I.400 Inp by serial en
It defines the bits of the mask, that are active for the virtual assignment. A byte is available for the selection of 8
digital inputs, whose setting has to be carried out as decimal value.
Bit 0 = 1 Enabled
Bit 1 = 2 Enabled
Bit 2 = 4 Enabled
Bit 3 = 8 Enabled
Bit 4 = 16 Enabled
Bit 5 = 32 Enabled
Bit 6 = 64 Enabled
Bit 7 = 128 Enabled
I.410 Exp in by ser en (Expansion inputs by serial line enabling)
Reserved.
I.420 Out by serial en (Outputs by serial line enabling)
It defines the bits of the mask, that are active for the virtual assignment. A 4 bits structure is available for the
selection of 4 digital outputs, whose setting has to be carried out as decimal value.
Bit 0 = 1 Enabled
Bit 1 = 2 Enabled
Bit 2 = 4 Enabled
Bit 3 = 8 Enabled
Code Name [Code] & Function. Default MIN MAX Unit Variation IPA
I.400 Inp by serial en 0 0 255 145
I.410 Exp in by ser en 0 0 15 146
I.420 Out by serial en 0 0 15 147
I.430 Exp OutBySer en 0 0 3 148
I.450 An out by ser en 0 0 255 149
Enabling of the encoder feedback management.
Serial Configuration
The DVS provides as a standard an RS485 serial line.
For the connection of the serial line, a 9-pin SUB-D connector, named JP7 or an AMP connector named JP15 (see
chapter 5.4.1 Serial Interface General). are available on the regulation card.
Through the serial line, all the parameters and variables can be written and read.
When control of the main command through serial line is needed, it is necessary to set the Cmd source sel (P.000) as
follows:
P.000 = 2 Terminal or Virtual
P.000 = 3 Serial
Further information are reported at the chapter PARAMETER, section Commands .
