3.4RACK MOUNTING
To installaGENH750W one unitortwo units side-by-sideinastandard 19”Rackin1U(1.75”)
height,use option kit P/N: GENH/RM.
The Rack Mount kit allows theunits to be zero stacked for maximum system flexibility and
power density without increassingthe 1U height of the units.
To installaGENH750W power supplyinastandard 19”Rackin1U(1.75”) height,usingaGENH
Rack Mount kit P/N: GENH/RM.
3.4.1Single unitinstallation
3.4.2 Dual unitinstallation
To installtwo GENH750W power supplies side-by-sideinastandard 19”Rackin 1U(1.75”)
height,usingaGENH Rack Mount kit P/N: GENH/RM.
Fig.31 Single unitinstallation
Fig.3-2 Dual unitinstallation
