Specifications
AMPLIFIER Section
Output Power .... 40 W + 40 W (6 ohms, 0.5 %, 1 kHz)
Input Sensitivity ................ PHONO: 2.5 mV 47 kΩ
AUX1, AUX2: 200 mV 47 kΩ
Frequency Response .... 20 Hz to 60,000 Hz (+1/–3 dB)
Subwoofer pre-out .................... 10 Hz to 35 kHz
TUNER Section
FM Section
Tuning Range ............... 87.50 MHz to 108.00 MHz
Signal-to-Noise Ratio ................... 65 dB (Mono)
60 dB (Stereo)
AM Section
Tuning Range ....................522 kHz to 1,629 kHz
Signal-to-Noise Ratio ............................35 dB
DAB Tuner
Tuning range ............ Band 3, 174 MHz to 240 MHz
Input ............................ 75 ohms, unbalance
Max signal ............................... –5 dBm typ
Sensitivity .............................. –97 dBm typ
Adjacent Channel Rejection ................ 35 dB typ
USB Section
Supply current of the USB port .............. 2100 mA
Playback
Format .............. LPCM,WAV,FLAC,MP3,WMA,AAC
Frequency Response ....... 20 Hz to 20,000 Hz (±2 dB)
Signal-to-Noise Ratio ................ more than 85 dB
Internet Radio
Format ......... WAV,FLAC,ALAC,MP3,OGG,WMA,AAC
Internet connection
LAN terminal ........................... 10/100 BASE-T
Wireless LAN ........................... IEEE 802.11b/g
Security .................... WEP, WPA-PSK, WPA2-PSK
GENERAL
Power Requirements .................. AC 230 V, 50 Hz
Power Consumption ........................... 120 W
0.5 W (standby)
Dimension (W x H x D) ........... 290 x 113 x 340 mm
Weight ........................................ 5.8 kg
Standard Accessories
Power Cord x 1
Remote Control Unit (RC-1286) x 1
Batteries (AAA) x 2
AM Loop Antenna x 1
FM Lead-type Antenna x 1
DAB antenna x 1
Owner’s Manual x 1
Warranty Card x 1
< Design and specifications are subject to change
without notice.
< Weight and dimensions are approximate.
< Illustrations may differ slightly from production
models.
